Armoring Wire Cable Accessories Aluminum Magnesium Alloy Strip Tape

Specifications

Brand Name :

HERRMAN

Model Number :

5052/5154/1060/3003

Place of Origin :

China (Mainland)

MOQ :

500

Price :

USD3/Kilogram

Payment Terms :

L/C, D/A, D/P, T/T

Delivery Time :

8 Working Days

Packaging Details :

Export Packing

Supply Ability :

100 Tons/ per month

Certification :

Tensile Strength (MPa) :

300-500

Usage :

armoring

Thickness :

0.5-0.8

Width :

150-500

Description

Aluminum Magnesium Alloy Strip Tape

Product specification							Mechanical properties
Name	Grade	Status	Thickness (mm)	Thickness Tolerance (mm)	Width (mm)	Width Tolerance (mm)	Tensile Strength (MPa)	Elongation%
Mechanical properties	5052 5154	H24	0.50	±0.02	±0.10	9.5	276~ 303	≥10%
			0.60			12.7
			0.65
			0.65			19
			0.75
			0.75			25.4
			0.80

FINISHED PRODUCT REWINDING CABLE ALUMIUM ALLOY STRIP
TECHNICAL PARAMETERS

Name	Grade	Statue	Width(mm)	Inside diameter(mm)	Outer Diameter(mm)	Single disk weight(kg)	Tensile force(kg)
Finished Rewinding belt	5052 5154	H24	150-500	200-450	850-1200	300-500	5-10

ALUMINUM BELT FOR ARGON ARC WELDING

Name	Grade	Status	Thickness(mm)	Thickness tolerance	Width (mm)	Width tolerance(mm)	Tensile strength	Elongation %
Argon Arc Welding Aluminum Belt	1060 3003	0	0.6	±0.02	40~100	±1.10	40~100 95~135	≥25 ≥20
			0.8		40~120
			1.0		80~200
			1.1		80~200
			1.2		80~200
			1.5		100~300
