Planetary Type Laying Up Machine Stranders

1200/1+6 Planetary type laying up machine

1. Usage

1.This Planetary type laying up machine is mainly used in insulated wire, rubber insulated wire, XLPE insulated wire,

The outer layer has taping or shielded braided layer.The machine starts and stops smoothly, and the operation and

maintenance are simple and convenient.Has easy operation touch screen and PLC system,The machine starts and

stops smoothly, and the operation and maintenance are simple and convenient.

2. Technical specification

3.Main components

3.1 6B stranding cage 1SET

3.2 Wire die holder 1SET

3.3 # type wire guiding stand 1SET

3.4 2000kg flat belt caterpillar 1SET

3.5 Wire supporting stand 1SET

3.6 Taping machine 2SETS

3.7 Meter counter 1SET

3.8 Ф2800 Column type take-up stand with traverse 1SET

3.9 Ф2500 Column type pay-off stand 1SET

3.10 Transmission system 1SET

3.11 Electric control system 1SET

4. Mechanical and electrical components

4.1 Main motors are from SIEMENS.

4.2 All the bearings are from Chinese famous brand.

4.3 All of the low-voltage electric elements are from Schneider.

4.4 PLC is from SIEMENSE

4.5 AC inverter is from SIEMENS.

4.6 Pneumatic elements are from AIRTAC

Note:(The product name of specific parts is mainly based on customer requirements)

5. PIicture

6.Drawing
