High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
Specifications
Brand Name :
Hooha
Model Number :
Hh-300
Certification :
CE,ISO,SGS
Place of Origin :
CHINA
MOQ :
1 Set
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets/year
Delivery Time :
60 working days
Packaging Details :
1. film packing 2. wooden package 3.enclosed wooden package
Model NO. :
HH-300
Type :
High-speed Stranding Machine
Usage :
Stranding
Inlet Wire Diameter :
0.08mm-0.25mm
Twisting Pitch :
0.8-10mm (Adjustable According to Customer Request
Rotation :
Stepless Speed Control , Max . 3500rpm
Specification :
L2400*W1300*H1450MM
Transport Package :
PE Plastic
HS Code :
8477209000
Description

High Quality 300 High Speed Bunching Machine Copper Wire Twisting Machine

Suitable Manufacturing Cable
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
Product Description

High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine

HH-T-300 High Speed Bunching Machine
It is suitable for stranding of the copper wires with more than seven strands, also suitable for electronic wires, power wires, bare copper wires, network wires etc.
Specification
Main parameters
Place of Origin
China
Brand Name
HOOHA
Model Number
HH-300
Usage
stranding
Certificate
ISO/Ce
Inlet wire diameter
Φ0.08mm--Φ0.25mm
Twist Cross section
0.035-1.0mm2
Twisting pitch
0.8-10mm (adjustable according to customer requests)
Twisting limit
for twisting more than 7 strands copper wire
Rotation
Stepless speed control , MAX . 3500rpm
Main Parts
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine

300 Bunching machine Pay off stand for 7 strands copper wire

Layout of Equipment

High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine

Company Profile

Our aim: To be a world-class supplier providing wire & cable manufacturing and using solution.
Our vision: To make wire & cable manufacturing and using more humanized.
Our target: More professional customer service, struggle for employees' dreams.
We are a Hong Kong company, focusing on in-depth cooperation with Chinese leading manufacturers to provide advanced wire&cable solutions.

Technical Team
Name
Education
Position
Mainly responsible for project
Specializing in project
Working history ( year )
Zanyang Xie
college
General Engineer
The total project design and planning
power cable machine
15
Xiaohua Hu
college
Vis general engineer
The total project design and planning
net cable,data cable machine
10
Changhong Cheng
college
Engineer
Drawings and after-sales service
Optical fiber cable machine
25
Xiuwu Chen
college
General Engineer
The total project design and planning
copper drawing machine
15
Lixin Yuan
college
Engineer
The project design and planning
coppwer wire making technical
16
Zhenghai Qiu
college
cable engineer
After service
cable making and cable factory management servie
15
Jinxin Liu
college
Marketing engineer
After service
electrical engineer
7
Xingguo Tang
High school
Electrical engineer
After service
electrical engineer
10
Changqiang Li
High school
Maintain engineer
After service
machina maintain and install service
10
Haipin Li
University
Engineering director
Marketing and sales
project consulting
8
Sen Yang
University
Engineering translator
Marketing and sales
project consulting
5
Customer Cases
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
Exhibitions & Certifications
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
Packaging and Delivery
High Speed Wire Bunching Machine , 0.08mm-0.25mm Copper Wire Twisting Machine
FAQ

1. who are we?
We are based in Guangdong, China, start from 2017,sell to Africa(17.00%),
Mid East(17.00%),
Southeast Asia(16.00%),
Eastern Asia(13.00%),
South Asia(10.00%),
South America(8.00%),
Eastern Europe(4.00%),
North America(3.00%),
Northern Europe(3.00%),
Southern Europe(3.00%),
Oceania(2.00%),
Western Europe(2.00%),
Central America(2.00%),
There are 5-10 professional workers in HOOHA.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Drawing Machine,Stranding Machine,Cabling Machine,Extrusion Machine,Bunching Machine

4. why should you buy from us not from other suppliers?
1.10 year R&D working experience with over sea service 2.5 big LV/MV cable project over 5 million working experience 3.After
service team has 30 country working experience 4. HOOHA team focus on the cable making and use solution supply chain.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
