Cage Type Planetary Wire Cable Stranding Machine With Back Twist
Cage Type Planetary Wire Cable Stranding Machine With Back Twist
Specifications
Brand Name :
yuyang
Model Number :
630-1+6+12
Certification :
CE, CCC, CE, ISO
Place of Origin :
dongguan,china
MOQ :
1 set
Price :
120,000$-180,000$
Payment Terms :
T/T, L/C
Supply Ability :
50 sets per year
Delivery Time :
90 days after advance payment
Packaging Details :
1 set 40 teet container
main power :
75kw
motor :
siemens
pay off :
630mm
inverter :
yaskawa
take up :
2500mm
copper :
35 50 70 95 square mm
finished OD :
50mm
copper details :
1+6+12
plc :
siemens
Stranding pitch :
60-1250mm
speed :
30m/min
Central height :
1000mm
Description

High Quality Cage Type Planetary Wire Cable Stranding Machine With Back Twist

The machine is mainly used for stranding bare conductors and insulated wires up to 30 strands.

Main technical parameters:

1.1 Single wire Dia. Copper: Φ1.5-Φ5.0mm / Insulated wire: Φ2-Φ7mm

1.2 Max stranded Dia. Ф50mm

1.3 Stranding pitch range 68-1250mm

1.4 Max cage rotate speed 12B: 70RPM / 18B:55RPM

1.5 Max line speed 30m/min

1.6 Capstan wheel diameter Ф1500mm

1.7 Central pay-off bobbin Ф500mm

1.8 Pay-off bobbin in stranding cage Ф500mm

1.9 Take-up drum Ф1000mm-Ф2000mm

1.10 Main motor power 55KW,380V,50Hz,AC motor

1.11 Central height of machine 1000mm

Components:

1.1 Ф1600mm column type pay off 1 set

  • Ф500/12+18 bobbins cages 1 set

1.3 Wire-stranded die holder 2 sets

1.4 Meter counter 1 pc

1.5 Ф1500mm double capstan wheels 1 set

1.6 Ф2000mm column type take-up and traverse 1 set

1.7 Transmission system 1 set

1.8 Electric control system 1 set

1.9 Safe fence 1 set

Main parts brand:

Main motor:SIEMENS Beide

Inverter:YASKAWA

Main low voltage electrical Components:Chinese famous brand

Main bearing:Chinese famous brand

Pneumatic elements:Chinese famous brand
