Black Color Polyester Fabric Wire Harness Wrapping Tape

Technical Parameters:

Product Description:

Wire Harness Wrapping Tape is an adhesive tape specially designed for automotive wire harness wrapping. The tape is made of high quality polyester fabric, providing excellent dielectric strength of ≥20KV/mm, excellent adhesion to steel of 2.5N/CM, and superior abrasion, temperature and noise damping. The tape is easy to use and install, making it ideal for automotive wire harness wrapping.

Fleece wiring tape is made from a non-woven polyester fabric material, which gives it a soft and flexible texture. The fabric is typically coated with an adhesive on one side, allowing it to adhere to wires and cables. The tape is often black in color, although other colors may be available for specific identification purposes.

The main purpose of fleece wiring tape is to protect the wires and cables from abrasion, moisture, and other external factors that may damage the insulation or conductivity. It provides a layer of insulation and helps to secure the wires in place, preventing them from moving or rubbing against each other.

Some advantages of fleece wiring tape include its flexibility, easy tearability, and repositionability. It can be torn by hand without the need for scissors or knives, making it convenient to work with. The tape can also be easily repositioned or removed if adjustments are needed during the wiring process.

Fleece wiring tape is commonly used in automotive, aerospace, and electrical industries. It is often used in wire harnesses, where multiple wires are bundled together, as well as in electrical repairs and installations. The tape is also used to provide additional insulation in high-temperature applications.

Here's a step-by-step guide on how to apply wire harness wrapping tape:

1. Prepare the wire harness: Ensure that the wires are properly organized and positioned before applying the tape. Remove any dirt, oil, or debris from the harness to ensure good adhesion.

2. Choose the right tape: Select a wire harness wrapping tape that suits your specific needs. There are different types of tapes available, such as cloth tape, vinyl tape, or fleece tape. Consider factors like temperature resistance, flexibility, and electrical insulation properties.

3. Position the tape: Hold the tape at a slight angle to the wire harness, making sure the adhesive side is facing the harness. Position the tape so that it overlaps the previous wrap by approximately half of its width.

4. Apply tension: Apply gentle tension to the tape as you wrap it around the wire harness. This tension helps create a secure and snug fit. Be careful not to pull too tightly, as it may damage the wires or restrict movement.

5. Overlap and continue wrapping: Continue wrapping the tape around the wire harness, maintaining the overlap and tension. Ensure that

each wrap slightly covers the previous one to provide a complete coverage.

6. Smooth out wrinkles and air bubbles: As you wrap, smooth out any wrinkles or air bubbles that may form. This helps ensure a neat and uniform appearance while maximizing the tape's protective properties.
