OEM Service SAE 100 R1 3/4 Inch Hydraulic Hose
OEM Service SAE 100 R1 3/4 Inch Hydraulic Hose
Specifications
Brand Name :
Yeli
Model Number :
HET20B1
Place of Origin :
China
MOQ :
1000Meter
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200,000 meter per month
Delivery Time :
15-20 working days
Packaging Details :
wrapped with yellow/white woven belt or plastic firm
Reinforcement :
1 layers of steel wire braid
Material :
Synthetic Rubber
Color :
Black
Size :
3/16" - 4"
Cover :
Weather Resistant Synthetic Rubber
Application :
Industrial,suitable to carry hydraulic fluids,used for hydraulic oil delivery,high imPUlse hydraulic applications.
Type :
R1. R2.
Temperature :
-40~100°C
Name :
High Pressure Hydraulic Rubber Hose
Surface :
cloth/smooth surface hydraulic hose
Sample :
Available
Working pressure :
4 to 25Mpa
Business type :
Manufacturer,Factory
Oem service :
Accept
Description

OEM Service SAE 100 R1 / 1sn One Wire Braid Hydraulic Oil Hose

Hydraulic Oil Hose SAE 100R1 3/16" 1/4" 3/8" 1/2" 3/4" 1" 1-4/1" 1-2/1" 2"

Applicable standards: EN 853 1SN / SAE 100 R1S / ISO 1436-1 1SN

OEM Service SAE 100 R1 3/4 Inch Hydraulic Hose

DN Hose I.D Hose O.D WorkingPressure Burst Pressure Minimum Bend Radius Weight Length
inch mm mm MPa MPa mm kg/m meters
5 3/16 4.8 11.5 25 100 90 0.201 20-100
6 1/4 6.4 12.7 22.5 90 100 0.244 20-100
8 5/16 7.9 14.4 21.5 86 115 0.274 20-100
10 3/8 9.5 16..5 18 72 130 0.363 20-100
13 1/2 12.7 19.5 16 64 180 0.447 20-100
16 5/8 15.9 23 13.0 52 200 0.539 20-100
19 3/4 19.1 26.7 10.5 42 240 0.690 20-100
25 1 25.4 34.5 8.7 35 300 0.987 20-50
32 1 1/4 31.8 42.2 6.3 25 420 1.205 20
38 1 1/2 38.1 48.9 5.0 20 500 1.405 20
51 2 50.8 61.9 4.0 16 630 1.910 20

Our Advantages


* Professional manufacturer for over 10 years in Hebei Province, near Tianjin or Qingdao port.
*Our product quality is top in China.
* Free hose sample is available.
* We can print words or your logo on the hose as your request.
* We test the products before shipping. We have a complete line of test machines.
* We ship the goods by sea, by air, by express according to your requirements.

OEM Service SAE 100 R1 3/4 Inch Hydraulic Hose
