Custom 900MHZ /1800MHZ GSM GPRS Antenna For Wireless Devices

Antenna introduction:

GSM module spring antenna , suitable for supporting SIM900A with a small board that can not install the antenna head , affordable

Key feature:

Diameter (mm): diameter 0.8mm, circle at the outer diameter of 5.4mm

Total length (mm): (with the length of the welded part) 18mm
The length of the welded portion (mm): 4.2mm

The antenna materials: Phosphor Bronze

The antennas color : phosphor bronze color
Interface in the form Connector Type: direct welding

Description:

Frequency Range(MHz): 824~960MHz / 1710~1990 MHz / 1920~2170 MHz
Bandwidth(MHz): CF±5MHz
Polarization: Linear
VSWR ≤2.5
Gain(dBi): 1
Max Input power(W):50
Input Impedance(Ω):50
Polarization Type :Vertical
Size(mm):Φ4.6x18 or customize
Material : Phosphor Copper
Temperature :-30°C to +75°C
Operating Temperature :-30°C to+75°C
Vibration : 10 to 55Hz with 1.5mm amplitude 2 hours
Environmentally friendly: ROHS Compliant

Specification:

Application:

GSM can be used for a variety of wireless devices currently used in most multi-kind, such as the CC1100 CC1020 NRF905 RF903 wireless modules and other products,

Click here to find the data sheet:

TOP-GSM-Spring 3-.pdf

Dimensions:

Package:

Our Antenna :

---Powerful R&D team

---Wonderful design solution

---Perfect after-sales service

---Strict quality testing

---Rich cooperation experiences with Communication product manufactures

---Competitive price

FAQ

1. What's the Warranty of the Products?

Answer: In general, all goods with 12 month-warranty after the shipments .

2. How about the defective rate ?

Answer: Less than 1%.

3. Where can customers get the Product Specification and other datasheets?

Answer: we will send them via email once get the request from the customers.

Our high quality products , competitive price and professional service, be sure to meet your need for all kinds of components. ^_^
