ZTE LTE 4G Wireless Serial Module ZM8620 With Qualcomm MDM9215 Chipset

ZM8620 V2/A

ZM8620 V2/B

ZM8620 V2/C

Introduction:

This is the new ZTE ZM8620 LTE (4G) wireless module supporting downlink data rates up to 100Mbps and uplink data rates up to 50 Mbps.

ZM8620 is a multimode wireless communication module with mini-PCIE interface, which can be applied in various industrial or consumer devices. ZTE ZM8620 has a wide range of LTE-FDD bands, but also TDD-bands.

This version V2/A is supporting FDD- bands 1/2/4/5/7/8/12 as well as TDD-band 38 and focused on the North American market.
There is also a V2/B version for the European/Asian market. Please see our product catalogue for further details about this product.

Specification:

Data Transfer Rate

LTE FDD: Downlink:100 Mbps, Uplink: 50 Mbps

LTE TDD: Downlink:61 Mbps, Uplink: 18 Mbps

HSDPA Rel 6: DL 14.4Mb/s

HSUPA Rel 6: UL 5.76Mb/s

HSPA+ Rel 7: DL 28/UL 5.76Mb/s

DC-HSPA+ Rel 8: DL 42/UL 5.76 Mb/s

Interface:

Antenna connector

PCIe interface

USB 2.0 High speed

PCM Voice

SIM Card

Power Supply:

3.0 V to 3.6 V (3.3 V recommended)

Voice. PCM Voice

GPS/Glonass. GPS Standalone,A-GPS

Special Features:

FOTA*(developing)

eCALL*(developing)

USSD

Operating System.

Linux, Android, Windows series

Key Advantage

ZM8620 is designed to provide customers with global network coverage on the connectivity of LTE. It delivers 50Mbp-up and 100Mbps-down data rates on LTE FDD networks and can also be fully backward compatible with existing UMTS and GSM/GPRS networks.

The mini PCIE form factor of ZM8620 has become a popular standard adopted by connected device manufacturers to easily integrate wireless connectivity into their devices for commercial and industrial computer markets.
Rx diversity which allows the end-device to be equipped with two distinct cellular antennas improving the quality and reliability of the wireless connectivity.

Appication :

A rich set of internet protocols (PAP and CHAP used for PPP connections)and abundant functions (GPS/A-GPS/LBS, USSD, Band Lock, Open RIL code, MMS, SMS) extend the applicability of the module to a wide range of M2M applications such as metering, tracking systems, security solutions, routers, wireless POS, mobile computing devices, PDAs, tablet PC and so on.
