PT250 OEM Pressure Transducer , Stainless Steel Pressure Sensor CE Approved
PT250 OEM Pressure Transducer , Stainless Steel Pressure Sensor CE Approved
Specifications
Brand Name :
Atech
Model Number :
PT250
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 pcs month
Delivery Time :
5-8 work days
Packaging Details :
standard export packing ,carton packing, water proof, shock resistance or according to customer's requirements.
pressure medium :
gas liquid compatible stainless steel
pressure ranges :
-1 – 0 bar ,0- 0.1bar, 0- 1000bar
display :
-1999 -9999 4 digital number with LED display
display accuracy :
+- 0.1%FS
accuracy :
<= 0.5%FS (standard)
long term stability :
0.5%FS/year
supply voltage :
10~30Vdc
operating temperature range :
-40~+85°c
Description

OEM Pressure Sensor PT250 Intelligent Pressure Switch

Feature

● With LED display

● Button set-up for various parameters, easy for operation

● Two way switch out put, Load capacity of 1.2A

● CE certificate

● Silicon sensor cell employed

Applications

● Industrial process control
● Machine tool
● Liquid pressure system and switch
● Vacuum furnace

Description

PT250 Intelligent pressure switch is a pressure measurement and control products with display and control. The product is all-electronic structure, preceding part use silicon oil-filled pressure sensor cell which has a insulation film. The processing output signal from the amplifier is given away with high accuracy A / D converter, converted into digital signals to control the two-way switches.

PT250 pressure switch is easy to operate, easy to debug, safe and reliable.

Speifications

pressure medium gas liquid compatible stainless steel
pressure ranges -1 – 0 bar ,0- 0.1bar, 0- 1000bar
supply voltage 24VDC
accuracy <= 0.5%FS (standard)
display -1999 -9999 4 digital number with LED display
display accuracy +- 0.1%FS
maximum power consumption <3W
supply voltage 10~30V
medium temperature range -40~85°c
operating temperature range -40~+85°c
storage temperature range -40~+85°c
switch type PNP /NPN
Switch endurance >1,000,000 times
insulation resistance >100MΩ@ 50VDC
process connection G1/4 or others
electrical connection DIN 43650 or others
long term stability 0.5%FS/year
material of pressure membrane 316L
Response time <=3ms
weight 210g
