1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137
Specifications
Brand Name :
TX TELSIG
Model Number :
YP163137
Certification :
SGS, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, Paypal,etc.
Frequency Range :
1500-1700MHz
Gain (Typ) :
31dB
Output Power :
5W
Quiescent Current :
50mA
Description

TXtelsig YP163137 RF Amplifier 1500-1700MHz 5W GaAs MMIC Power Amplifier

The YP163137 is a high-power, high-efficiency Power Amplifier intend for Compass Satellite Communication and Navigation. The Power Amplifier provides a typical gain of 31 dB and P1dB of 37dBm with CW input, typical quiescent bias condition is 6.0V at 50mA. The device is manufactured on an advanced InGaP/GaAs Heterojunction Bipolar Transistor (HBT) process. The YP163137 is assembled in a 16-pin, 4mm×4mm, QFN package, it is internally integrated with ESD protection unit.

Features
■ 1.5~1.7GHz Frequency Range
■ 31dB Gain (Typ)
■ ≥37dBm P1dB with CW Signal Input
■ ≥17dB Input Return Loss
■ 3.3~6.0V Operation
■ 50mA Quiescent Current
■ Integrated Output Power Detector
■ Integrated ESD Protection Unit
■ Advanced InGaP/GaAs HBT Technology

Applications
■ Compass Satellite Communication
■ Compass Satellite Navigation

Caution! ESD Sensitive Device:

ESD Rating: Class1C
Value: Passes≥1000V min.
Test: Human Body Model (HBM)
Standard: JEDEC Standard JESD22-A114

ESD Rating: Class IV
Value: Passes ≥1000V min.
Test: Charged Device Model (CDM)
Standard: JEDEC Standard JESD22-C101

MSL Rating: Level 3 at +260 °C convection
reflow
Standard: JEDEC Standard J-STD-020

Parameter Rating Unit
Input RF Power 10 dBm
Supply Voltage -0.5 to +6.0 V
Bias Voltage -0.5 to +3.0 V
DC Supply Current 2200 mA
Operating Ambient Temperature -40 to +85 °C
Storage Temperature -40 to +150 °C

1500 - 1700MHz 5W GaAs MMIC Power Amplifier , Uhf Linear Amplifier YP163137

Pin Description
Pin No. Symbol Description
2 RF IN RF input
4, 7 VREF1&2, VREF3 Bias current control voltage
5 VCCB Supply voltage for bias
6 VCTR Power on/off control voltage
9, 10, 11, 12 RF OUT (VCC3) RF output and stage 3 collector voltage
13 VCC2 Stage 2 collector voltage
14 PDET Power detect
15 VCCD Supply voltage for power detector
16 VCC1 Stage 1 collector voltage
1,3,8 NC/GND No connection or ground
