Specifications
Brand Name :
TeXin
Model Number :
TX-50W
Certification :
CE ISO
Place of Origin :
Shenzhen China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100000/month
Delivery Time :
within 3 days
Packaging Details :
durable case or box
Type :
Professional Amplifier
Frequency Range :
customzied
Weight :
200g
Size :
132*53*17
Test Voltage :
24-28V
Color :
sliver
Warranty :
1year
Output Power :
50W
Material :
Aluminium Alloy
Application :
Signal Jammer Filed
Product Name :
5.2 G 50w signal power amplifier module
Power Supply :
Red+black+enable Wire
Max Gain :
47dBm
Description

Product description

The 5.2G 50W signal power amplifier module is a specialized electronic component designed to amplify radio frequency (RF) signals in the 5.2 GHz frequency range. TeXin is a leading China module manufacturer, supplier and exporter. Adhering to the pursuit of perfect quality of products, so that our module have been satisfied by many customers.

5.2 G 50w signal power amplifier module
The 5.2G 50W signal power amplifier module is designed to operate efficiently at the 5.2 GHz frequency with stable performance and minimal distortion. Its Input and output ports are usually designed to handle RF signals with specific impedance (commonly 50 ohms) to ensure impedance matching and minimize signal reflections.

High Power 5.2G 50W Signal Power Amplifier Module Max Gain 47dBm For Anti Drone

High Power 5.2G 50W Signal Power Amplifier Module Max Gain 47dBm For Anti Drone

High Power 5.2G 50W Signal Power Amplifier Module Max Gain 47dBm For Anti Drone

5.2 G 50w signal power amplifier module specification

No. Item Data Unit Notes
1 Frequency 5.2 GHz
2 Work Temperature -20~+70 ℃
3 Max Output Power 50 W
4 Work Voltage DC28 V
5 Max Gain 47 dB
6 Flatness ±1 dB　
7 Max Current 4 A
8 Output VSWR ≤1.5
9 Output Connector SMA/F 50Ω Customized
10 Power Amplifier Efficiency 45 when Max Output
11 Switch Control

high low

level current

 V 0V off /0.6 on
12 Standing Wave Protection OK
13 Temperature Protection 75° ℃
14 Size 132*53*17 mm
15 Weight 0.2 Kg

High Power 5.2G 50W Signal Power Amplifier Module Max Gain 47dBm For Anti Drone
