Go Devil Cutter Bar Type Wireline Fishing Tool 5ft Length
Go Devil Cutter Bar Type Wireline Fishing Tool 5ft Length
Specifications
Brand Name :
Ruixin
Model Number :
1.5inch 1.875inch 2.125inch 2.5inch
Certification :
API Q1
Place of Origin :
China Baoji
MOQ :
1
Payment Terms :
T/T, Western Union
Supply Ability :
1 set 3 weeks
Delivery Time :
3-4 weeks
Packaging Details :
Wooden Box
Name :
GO Devil Cutter Bar type Wireline Fishing Tool
Size :
1.5inch 1.875inch 2.125inch 2.5inch
Material :
Alloy Steel
Use :
Wireline &Slickline
Fish Neck :
1.187inch 1.375inch 1.75inch 2.313inch
Length :
2ft 3ft 5ft
Service :
Standard &H2S
Description

GO Devil Cutter Bar type Wireline Fishing Tool

I. Overview:

The GO Devil Cutter Bar type is used to cut the stuck tool string wire.

The GO Devil Cutter Bar type is composed of a solid rod with a groove and a guide surface. It goes into the well in a conventional way. If there is no foreign matter on the rope cap, the inclined plane of the cutter will directly cut the steel wire on the rope cap. When the steel wire tool is seriously buried by sand, debris or steel wire, or it is not cut at one time. It can be struck again with a flat-bottomed wire cutter.

The steel wire cutter is provided with a positioning groove for installing the slip centralizer, which can be used in large diameter oil pipes after installing the slip centralizer.

II, the commonly used technical parameters:

Size Fishing neck length Applicable steel wire specification
1.5＂ 1.375＂ 2ft 0.092＂～0.108＂/7/32＂～3/16＂
1.5＂ 1.375＂ 3ft 0.092＂～0.108＂/7/32＂～3/16＂
1.5＂ 1.375＂ 5ft 0.092＂～0.108＂/7/32＂～3/16＂
1.875＂ 1.75＂ 2ft 0.092＂～0.108＂/7/32＂～3/16＂
1.875＂ 1.75＂ 3ft 0.092＂～0.108＂/7/32＂～3/16＂
1.875＂ 1.75＂ 5ft 0.092＂～0.108＂/7/32＂～3/16＂
2.125＂ 1.75＂ 2ft 0.092＂～0.108＂/7/32＂～3/16＂
2.125＂ 1.75＂ 3ft 0.092＂～0.108＂/7/32＂～3/16＂
2.125＂ 1.75＂ 5ft 0.092＂～0.108＂/7/32＂～3/16＂
2.5＂ 2.313＂ 2ft 0.092＂～0.108＂/7/32＂～3/16＂
2.5＂ 2.313＂ 3ft 0.092＂～0.108＂/7/32＂～3/16＂
2.5＂ 2.313＂ 5ft 0.092＂～0.108＂/7/32＂～3/16＂

III. Structural characteristics and use:

The GO Devil Cutter Bar type is composed of a grooved inclined-bottom solid rod and a baffle. The baffle is connected with the grooved solid rod by screws. When in use, the baffle is removed, the steel wire is clamped into the groove, and then the baffle is installed. The steel wire cutter runs down the steel wire into the well and cuts the steel wire at the head of the rope cap. Then, the wire cutter and tool string are fished out with a fishing device.

IV. Precautions:

When using the inclined bottom wire cutter, make sure there is no foreign matter above the rope cap. Otherwise it cannot cut the steel wire. Secondly, after using the inclined bottom wire cutter, timely and carefully maintain it to prolong the service life of the tool.

Welcome to contact us at any time.

Go Devil Cutter Bar Type Wireline Fishing Tool 5ft Length
