Wireline Fishing Lead Impression Block 1.0 Inch 15/16-10UN
Wireline Fishing Lead Impression Block 1.0 Inch 15/16-10UN
Specifications
Brand Name :
Ruixin
Model Number :
1.0inch-6inch
Certification :
API
Place of Origin :
China Baoji
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1 set 2 weeks
Delivery Time :
2-3 weeks
Packaging Details :
Wooden Box
Name :
Wireline Fishing Tool Lead Impression Block
Size :
1.0inch-6inch
Fishneck O.D. :
1.187inch-3.125inch
Connection Type :
15/16-10UN 1-1/16-10UN 1-9/16-10UN
Description

Wireline Fishing Tool Lead Impression Block

I. Overview:
The lead printing is used to print the shape and size of the fish in the well, so as to determine the tools and measures that should be used in the next fishing operation.
II. Technical parameters:

Tools O.D. Fishneck O.D. Connection Type
1.0＂～1.5＂ 1.187＂ 15/16-10UN
1.5＂～2.0＂ 1.375＂ 15/16-10UN
2.0＂～2.5＂ 1.375＂ 15/16-10UN
2.5＂～3.0＂ 1.75＂ 1-1/16-10UN
3.0＂～4.0＂ 2.313＂ 1-1/16-10UN
4.0＂～5.0＂ 2.313＂ 1-1/16-10UN
5.0＂～6.0＂ 3.125＂ 1-9/16-10UN

Special specifications can be provided according to customer requirements
III. Structural features and use:
1. The lead stamp is a tool for filling lead in the pipe sleeve. When the lead print hits a falling object with a higher hardness downhole, it deforms, and the shape and size of the falling object are recorded. After use, the traces can be cleaned up, stored carefully, and can be recycled until the exposed lead body is used up.
2. When going down the well, it is connected to the basic tool string to go down the well.
3. Go down to the place of the falling object and hit it slightly downwards once. (Note: Do not repeat the shock, so as not to reprint the figure on the lead, which will make it impossible to judge the shape and size of the fish.
IV, matters needing attention:
The lead print must be well protected during transportation and storage, and no bumps are allowed.
