Specifications
Brand Name :
RuiXin
Model Number :
6BX(4-1/16)5KX6BX(4-1/16)10K
Certification :
API
Place of Origin :
China BaoJi
MOQ :
1
Payment Terms :
T/T
Supply Ability :
1 set 1 weeks
Delivery Time :
2-3 weeks
Packaging Details :
Wooden Box
NAME :
Flange Half Moom Flange Wellhead Adapter Wireline Pressure Control Equipment
Mobel :
6BX(4-1/16)5K X 6BX(4-1/16)10K
RATED OPERATING PRESSURE :
35Mpa
STRENGTH TEST PRESSURE :
52.5Mpa
FLANGE GASKET RING MODEL :
BX155 / R39
Stud specifications :
1-1/8-8UN×8.5inch / 1-1/4-8UN×8.5inch
WEIGHT :
77.3KG
MATERIAL :
Alloy Steel&Nickel Alloy
OPERATION :
Wireline Operation And Slickline Operation
Description

Flange Half Moom Flange Wellhead Adapter Wireline Pressure Control Equipment

Overview

The wellhead flange is used to connect the wellhead, the upper part is connected to the tubing , and the lower part is connected to the wellhead. The wellhead flange is connected by bolts and nuts. When in use, the gasket is placed between the sealing surface, after tightening the nut, the specific pressure on the surface of the gasket will be deformed after reaching a certain value, and the uneven part of the sealing surface will be filled, so that the connection is tight and does not leak.

Pressure test

The wellhead flange should be regularly tested for compressive strength, and the test pressure is 1.5 times the working pressure.

1. Install the pressure test connector and connect the pressure test hose ;

2. Start the pressure test pump for pressure test: press to the test pressure, hold the pressure for 15 minutes without leakage, fill in the test record card.

Technical parameters

MOBEl 6BX(4-1/16)5K X 6BX(4-1/16)10K

RATED OPERATING PRESSURE 35Mpa

STRENGTH TEST PRESSURE 52.5Mpa

FLANGE GASKET RING MODEL BX155 / R39

STUD SPECIFICATIONS 1-1/8-8UN×8.5inch / 1-1/4-8UN×8.5inch

WEIGHT 77.3KG

COLOURS According to customer needs

Flange Half Moom Flange Wellhead Adapter Wireline Pressure Control Equipment

Any size can be customized according to customer requirements.

Routine maintenance

1. The pressure test should be carried out regularly;

2. When not in use for the time being, should bring the protective wire storage.

◆About Baoji RuiXin Slickline Tools

Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.

Strict quality control system

Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.

Hard work, after-sales service

On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.

Welcome to contact us at any time.
