Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Duplex 2205 2507 Stainless Steel Wire Mesh Plain Weave Solid Structure Long Lifespan
Specifications
Brand Name :
Yoston
Model Number :
Stainless Steel Wire Mesh
Certification :
ISO 9001:2008 / CE / EN / SGS
Place of Origin :
China
MOQ :
1 M2
Payment Terms :
L/C, T/T
Delivery Time :
5-8 days
Packaging Details :
Water proof paper inside outside with Carton or Wooden Case
Materials :
ASTM 202 / 304 / 316 / 316L Etc.
Weaving Type :
Plain weave, Twill weave, dutch weave
Mesh :
1- 100 mesh
Advantage :
have stock mostly
Application :
Industrial filter
Name :
stainless steel screen wire
Description

Duplex stainless steel 2205 2507 plain weave wire mesh suppliers

The Duplex alloys offer a mixed austenite and ferrite microstructure, combining many of the beneficial properties of both. Characterized by high chromium and nitrogen, they are special grades of stainless steel that have improved resistance to pitting and crevice corrosion, particularly in marine applications.

1. Material: Duplex 2205, 2507 etc.

2. Wire Dia: 0.1-- 0.4 mm

3. Mesh:20- 100mesh ( have stock )

5. Weave pattern: plain weave, twill weave,etc

Stainless Steel Mesh Specification (Plain Weave)
Mesh Wire Dia Aperture
Inch mm Inch mm
20X20 0.02 0.51 0.03 0.76
20X20 0.016 0.41 0.034 0.86
24X24 0.014 0.36 0.0277 0.70
30X30 0.013 0.33 0.0203 0.52
30X30 0.012 0.31 0.0213 0.54
30X30 0.009 0.23 0.0243 0.62
40X40 0.01 0.25 0.015 0.38
50X50 0.009 0.23 0.011 0.28
50X50 0.008 0.20 0.012 0.31
60X60 0.0075 0.19 0.0092 0.23
60X60 0.007 0.18 0.0097 0.25
80X80 0.0065 0.17 0.006 0.15
80X80 0.0055 0.14 0.007 0.18
100X100 0.0045 0.11 0.0055 0.14
100X100 0.004 0.10 0.006 0.15
100X100 0.0035 0.09 0.0065 0.17
120X120 0.0037 0.09 0.0064 0.12
150X150 0.0026 0.07 0.0041 0.10
160X160 0.0025 0.06 0.0038 0.10
180X180 0.0023 0.06 0.0033 0.08
200X200 0.0021 0.05 0.0029 0.07
250X250 0.0016 0.04 0.0024 0.06
300X300 (SS316) 0.0051 0.04 0.0018 0.05
325X325 (SS316) 0.0014 0.04 0.0017 0.04
400X400 (SS316) 0.001 0.03 0.0015 0.37
500X500 (SS316) 0.001 0.03 0.001 0.03
635X635 (SS316) 0.0008 0.02 0.0008 0.02
