Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Specifications
Brand Name :
LNF-358 security mesh fence
Model Number :
3.00mm wire 4.00mm wire 12.70mm*76.20mm
Certification :
ISO
Place of Origin :
South African Design China Made
MOQ :
500 liner meter
Price :
16.66$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 Steel
Mesh Opening :
3" x 0.5" x 8gague wire,12.70mm x 76.20mm
Diameter :
4.00mm ,3.00mm
Size :
Available Customized
Color :
All RAL color card
Treatment :
Hot Dipped Galvanized Or Powder Coated
V Beams :
Available
Sample :
Free but pay freight cost
Accessoires :
Clamp,Post ,Y arm for barb wire
Feature :
Anti ,Resistant ,Cut ,Climb
Main Market :
Africa ,Oceania ,Aisa
Salt Spray Test :
Pass
Description

Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire rigidity panels

Anti security fence is the ultimate security fencing system. The close mesh is used in prisons and other secure facilities as it is virtually impossible to climb. The close mesh also means that the fence is very difficult to cut with anything but power tools.
The high security fencing system has been recently developed to make it more secure than ever. The panels are covered by a continuous heavyweight clamp bar, which offers no place for leverage to prise it off. The system also has no removable fixings meaning that panels cannot be removed by would be intruders.
The system also utilises cylindrical corner posts meaning that the fence line can run off at any angle, meaning that the fence is easy to install in almost any situation.
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
fence model
height of fence range (mm)
width of panel range
(mm)
wire dia range (mm)
mesh opening (mm)
post size type
(mm)
358 fence
Anti-climb fence
800-2500
2000-3100
3.0-5.0
12.6*76.2
square post :
60*60, 80*80
12.5*75
C post
60*80mm
25.*75
H post :
44*100
popular panel size
1800*2400
2100*2400
2400*2400
2200*2800
popular post size
60*60*2.0(thk)
60*80*2.0(thk)
60*60*2.2(thk)
60*60*2.5(thk)
60*80*2.2(thk)
surface treatment
1. Black wire welded then hot-dipped galvanized only
2. Galvanized with then powder coated
3.Galvanized with then pvc coated
High security anti-climbing fence features
  • Good viewing visibility, it is a type of high security clear view fencing.
  • Welded well at each intersection.
  • Intrusion resistant, with extremely strong double vertical wire design.
  • Small mesh aperture, anti-cut, anti-climb, finger-resistant and toe-resistant.
  • Corrosion resistant with zinc aluminum alloy and PVC powder coating.
  • Surface finish after welding, every weld-point are protected well.
  • High strength with fully integrated with posts and anti-tamper fixings.
  • Fence security toppings are optional.
  • Easy for installation and free maintenance.
  • 5 year warranty.
Anti climb fence specifications:
  • Wire: 4 mm steel wire.
  • Wire surface finish: galfan coating after welded, and then PVC powder coating (Min. 120 micron), or PVC powder painting.
  • PVC coated color: black, dark green, brown, yellow, desert sand, bronze or other colors request.
  • Mesh opening pattern: 70 mm × 8 mm, welded well at each intersection.
  • Mesh sheet width: 2515 mm.
  • Anti-climb mesh fencing panels and posts.
Details Images
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Product packaging
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
Product Paramenters
Table-1: anti-climb mesh fencing panels and posts specifications
Fence height (m)
Panel size
Fence Post
Clamp Bar
Inter or corner
(Height × Width)
(Height × Size × Thick)
(Height × Width × Thick )
Clamp No. (PCS)
2
2007 mm × 2515 mm
2700 × 80 × 80 × 3 mm
2007 × 60 × 5.00 mm
7 or 14
2.4
2410 mm × 2515 mm
3100 × 80 × 80 × 3 mm
2400 × 60 × 5.00 mm
9 or 18
3
3010 mm × 2515 mm
3800 × 100 × 100 × 3.0 mm
2997 × 80 × 6.00 mm
11 or 22
3.6
3610 mm × 2515 mm
4500 × 100 × 100 × 3.5 mm
3607 × 100 × 7.00 mm
13 or 26
Note: anti-climb mesh fencing can be custom ordered to measure.
Anti-climb fence with double vertical wire provides an ideal solution for high security perimeter and access control applications, such as:
  • Prison perimeter areas.
  • Military sites and government facilities.
  • Electricity distribution sites.
  • Airports, railways, roadways.
  • Seaports.
  • Fencing & intrusion detection projects.
  • Hydel power project.
  • Petroleum and chemical facilities.
  • Wildlife sanctuaries.
  • Warehousing facilities,
  • School.
Military anti-climb 358 high-security fences also Called Cochrane fence Good Sales In African Market With The Post Size: 85 x 85 x 45mm x 3.00mm thick. We Are The China Only Manufacturer Can Supply and Manufacturing Completely Fencing System
Specifications
358 high security fence
1>wire dia: 3.0-4.0mm
2>panel: 2400X2515,2500X3000mm
3>opening: 76.2X12.7mm
4>factory&exporter
1. 358 high-security fences brief introduction:
•It is named by its specification:
Material: low carbon steel wire, Aluminum magnesium alloy wire
Mesh Aperture: 76.2mm x 12.7mm (3'' x 0.5'')
Wire Dia.: 4mm (Gauge 8), 3mm(Gauge 10)
•It has two product specifications:
358 fence: 76.2mm x 12.7mm (3'' x 0.5''), Wire Dia: 4mm (Gauge 8)
3510 fence: 76.2mm x 12.7mm (3'' x 0.5''), Wire Dia: 3mm (Gauge 10)
Clearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panelsClearvu Security Fence ,High Security 12.70mm x 76.20mm x 4.00mm wire ridity panels
