Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
Specifications
Brand Name :
LNF-Chain link Fence Panels
Model Number :
4'6'8' Height
Certification :
ASTM
Place of Origin :
American Design China Made
MOQ :
1700 liner ft
Price :
4.00$/liner ft
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner ft
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 Steel Pipes and Wire
Mesh Opening :
2"x2"/(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜"x2⅜"(60mmx60mm) 2½"x2½"(63mmx63mm)
Diameter :
10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Type :
chain mesh
Color :
Silver and HDG steel
Warranty :
5-15 years depand on treatment
Customized :
Available
Size :
6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Feet :
36" length x 30" width x 8"Height /914mmx762mmx203mm
Accessoires :
Top Couper
Description

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Product parameters

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

chain link fence
Type Wire dia Hole Size Length height Post size
Round
C11 2mm 4cm*4cm 3m 2.5m 6cm*3mm
C12 2.5mm 5cm*5cm 3m 2m 5cm*2mm
C13 3mm 5cm*5cm 3m 1.8m 5cm*1.5mm
C14 3mm 6cm*6cm 3m 2.5mm 6cm*3mm
C15 4mm 5cm*5cm 3m 2m 5cm*2mm
C16 4mm 6cm*6cm 2.5m 1.8m 5cm*1.5mm
C17 4mm 7cm*7cm 3m 2.5m 6cm*3mm
C18 4.5mm 5cm*5cm 3m 2m 5cm*2mm
C19 4.5mm 6cm*6cm 2.5m 1.5m 5cm*2mm
C20 4.5mm 7cm*7cm 3m 2m 5cm*3mm
C21 5mm 5cm*5cm 3m 1.8m 5cm*2mm
Special request can be customized.ADS Chain Link Fence is your Best Choice!

Surface Treatment

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Material:hot-dip galvanized low carbon steel wire,Zinc-5%Al or 10%Al-mixed rare earth alloy coating,

also named Galfan

1) normal zinc coating(40-60g/m2)

2) heavy zinc coating (200-280g/m2)

3) Galfan 5%Al-zinc coated steel wire(200-500g/m2)

Galfan 10%Al-zinc coated steel wire(200-500g/m2)

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Material:PVC coated Wire

PVC coated on electro galvanized wire,hot-dip galvanized steel wire and Galfan wire

Variety of colors can be chosen based on the color brochure

Product Description

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Application

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

8 gauge chain link fence for sale factory is practical in lots of situations.It has many advantage over similar fences.

For example,it's easy to install and has a effective cost. This kind of fence widely used for

both residential and commercial field,such as schoolyards,industrial property, tennis courts,

baseball fields residential yards and so on.

1. Chain Link, Temporary fence is also known as Temporary fencing, temporary fence panels, portable fence, Temp fence, temp fencing, and mobile fence. It is consist of chain link panel, round tube frame, plastic feet, stays, and clamps. This kind of fence has a superior structure, globality, mobility, and environmental suitability is very good.

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

2.Common product specification:

Material

low carbon steel wire, Q195

carbon steel pipe, Q235

US Standard Specification

Wire diameter:2.7mm

Mesh opening:58x58mm,60mm*60mm,50mm*50mm

Frame pipe:32mm O.D.33.4mmO, D

Pipe thickness:2.0mm--3.0mm

HXL:6'*8'

Surface finish

(Hot dipped galvanizing)

Wire zinc coating

About 200g/m2(28 microns)

Pipe zinc coating

About 300g/m2(42 microns)

Fence base

Hot dipped galvanizing, sizes are suited to the pipe diameter.

Base feet size

762x460mm,customized colors

Package

On steel pallet

3. Chain link fence features:

1). It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.

2). Weather resistant and durable, and will last much longer; The temporary fences are light and easy to handle while being strong and robust at the same time;

3). The feet are removable which makes transportation and storage much easier and more efficient

4). Easy to Erect - four meters a minuteSecurity site fencing panels 6x12 feet /chain link temporary fencing direct factory

Light and easy to handle

Create a gate at any point on the perimeter

Economical temp fence - can be used time after time

Delivered accompanied by forklift for easy distribution

Constructed from heavy gauge galvanized tube and welded mesh infill

4.Construction chain link fence productive process:

Pre-hot dip galvanized wire drawing--- cut wire and pipes ---wire weave---cut the corners of the mesh---Pre hot dip galvanized pipes welded—polish the welds—paint anti-rust epoxy—spray silver powder coat on each weld—stacking—the packaging

Wire weaving-Frame tube production-Tighten chain link fence panel to frame tube-Finished chain link fence panels

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Galvanized base feet:

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Powder coated base feet:

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

6.chainlinkconstruction fence in stock:

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory

Security site fencing panels 6x12 feet /chain link temporary fencing direct factory
