Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
Specifications
Brand Name :
LNF-2d fencing panels
Model Number :
868 and 656 twin wire
Certification :
ISO
Place of Origin :
Europea Design China Made
MOQ :
500 liner meter
Price :
3.88$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Description

Decorative Metal Arched Wire Mesh Fence, Decorative Powder Coated Arched Top Metal Fence

The specification of the double rod mats fence panel
Panel(mm)
Width*Height
Mesh Size
(mm)
Wire Dia
(mm)
Post Height
(mm)
630*2500
50*200
8*2+6

6*2+5
6*2+4
1100
830*2500
50*200
8*2+6
6*2+5
6*2+4
1300
1030*2500
50*200
8*2+6
6*2+5
6*2+4
1500
1230*2500
50*200
8*2+6
6*2+5
6*2+4
1700
1430*2500
50*200
8*2+6
6*2+5
6*2+4
1900
1630*2500
50*200
8*2+6
6*2+5
6*2+4
2100
1830*2500
50*200
8*2+6
6*2+5
6*2+4
2400
2030*2500
50*200
8*2+6
6*2+5
6*2+4
2600
2230*2500
50*200
8*2+6
6*2+5
6*2+4
2800
2430*2500
50*200
8*2+6
6*2+5
6*2+4
3000
The Specification of the double rod mats fence Post
Post
Size
Thickness
Square post
50*50m 60*60mm 80*80mm 100*100mm
1.5mm 2.0mm 2.5mm
Rectangular post
40*60mm 60*80mm 80*100mm
1.5mm 2.0mm 2.5mm
Peach post
50*70mm 60*90mm 70*100mm
1.5mm 2.0mm 2.5mm
Production Process
Installation display
Product Applications
double welded wire mesh fence can be used for supermarket shelves, exhibition sample holder, fence,residential villa garden fence, the stadium fence, yard fence, highway,highway, airport, seaport, fence, poultry and livestock, which is widely used in industry, agriculture, transportation, farming and other industries.
This kind of panel is welded by 4mm - 6mm (before treatment) high-strength iron wire, assembled with strength posts. The unique pattern design on the top enhance the anti-climb capacity, perfectly combined with security functions and aesthetic design. There are various optional parts for higher security needs, can be used in many areas.
Specification of Decorative Powder Coated Arched Top Metal Fence
Wire Diameter
Mesh Size
Panel Height
Panel Width
Post Height
Post Type
Fittings
5/6/5mm
6/5/6mm
6/6/6mm
8/6/8mm
50x200mm
60x150mm
50x100mm
630mm
2000mm
2200mm
2500mm
3000mm
1000mm
Becaclip Post
Non clamps,
Rain cap
830mm
1200mm
1230mm
1400mm
Square Post
Steel clamp,
Plastic clamp,
Rain cap
1530mm
2000mm
1830mm
2400mm
2030mm
2600mm
Round Post
Steel clamp,
Plastic clamp,
Rain cap
Features of Decorative Powder Coated Arched Top Metal Fence
1> Vandal resistant, Low maintenance
2> Strong and reliable security
3> Simple structure, Attractive appearance
4> Easy installation, Convenient transport
Application of Decorative Powder Coated Arched Top Metal Fence
1>Public building fence
2>Private place fence, Where visibility is desirable
3>Residential perimeter fence
4>In Parks, Zoos and nature reserves
3. Features:
1. Material: Low-carbon steel wire Q195 (black wire, galvanized wire)
2. Wire Diameter: 4/5/4; 5/6/5; 6/5/6; 8/6/8 mm as standard
3. Surface Treatment: Electro-galvanized, Hot-dipped galvanized, PVC coated, Power coated
4. Material: high-quality low carbon steel wire Q235/Q195/S235J2, galvanized wire, plastic coated wire
5. Process: welding--making folds---galvanized/hot-dipped---powder coated---packaging
6. Colors: green RAL6005,red,yellow,whiteRAL9010 and so on.Dark Green RAL6005 is most popular
4. Applications:
1. Public building fence
2. Private place fence, Where visibility is desirable
3. Residential perimeter fence
4. In Parks, Zoos and nature reserves
5. Advantages:
1. Vandal resistant, Low maintenance
2. Strong and reliable security
3. Simple structure, Attractive appearance
4. Easy installation, Convenient transport
6. Product Show:
Decorative Metal Arched Wire Mesh Fence,Decorative Powder Coated Arched Top Metal Fence
