Specifications
Brand Name :
LNF-ClearVU Wire Fence
Model Number :
3"x0.5"x 8ga wire euqal to 12.70mm x 76.20mm x 4.00mm wire
Certification :
ISO
Place of Origin :
South African Design China Made
MOQ :
500 liner meter
Price :
18.88$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 Steel
Mesh Opening :
3" x 0.5" x 8gague wire,12.70mm x 76.20mm
Diameter :
4.00mm ,3.00mm
Size :
Available Customized
Color :
All RAL color card
Treatment :
Hot Dipped Galvanized Or Powder Coated
V Beams :
Available
Sample :
Free but pay freight cost
Accessoires :
Clamp,Post ,Y arm for barb wire
Feature :
Anti ,Resistant ,Cut ,Climb
Main Market :
Africa ,Oceania ,Aisa
Salt Spray Test :
Pass
Description
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
358 mesh fence, another names are high security fence, 358 fence, anti-climb fence, anti-cut fence, or clear vu fence. The most special specs of 358 mesh fence is its mesh size – 76.2mm*12.7mm. Of course, the small mesh brights the anti-climb and anti-cut function of the 358 mesh fence. Usually the weight of 358 mesh fence is about three or four times of other kind of wire mesh fencing because the dense wires need much more material than other kinds. Producing a piece of good quality 358 mesh fence use a good welding machines is not enough, also needs a skilled welding worker. To control the machine speed and proofread the direction of wires are very important. If production speed is too fast, the wire will be over heated and need man made proofread the wire to be correct position.
358 mesh fence is wildly used for the places need high security protection, such as prison, military zone and other places need or have lower security control. The main market of 358 mesh fence is in South Africa, United States and Nigeria. Mostly the clients prefer hot dipped galvanized surface treatment.
Specification
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
Product Name
358 Fence
Material
Low carbon steel wire
Surface Treatment
Power Coated
Panel Height
1.8m-5m
Panel Width
2.0m,2.2m,ect
Mesh Opening
3 inch * 0.5 inch
Wire Diameter
4mm to 6mm
Post
Square Post
60x60x2/2.5 or 80x80x2.5/3
Accessary
Flat Bar,Screw,Clamp
Features
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
High Security
Anti-Climb
Anti-Cut
358 mesh fencing is famous of its high security function. The small mesh (76.2mm*12.7mm) is small enough for human finger or cutter go though, so that’s the reason why its another two names are anti-climb fence and anti-cut fence. 358 mesh fence is wildly used in military zone or prison because of its high security function.
The mesh size of 358 mesh fence is 76.2mm*12.7mm which is to small for human’s finger to go though.
Cutting the wire of 358 mesh fence is also a problem for the people trying to go through. The normal scissors can go through the mesh but it is not power enough for cutting the wire off. If change it to more powerful cutter, then the cutter will be too big to go through the mesh. Normal tools can not cut the wire off.
Secure-net anti-climb fence is also called high-density mesh fence or anti-terrorist mesh fence. It is designed for the high-security area with high strength steel post, high density welded mesh panel, prevent remove fittings and connection and integrated security annex configuration(sawtooth, extension arms, barbed wire and razor ribbon roll). Anti-cut and anti-clamp design make the fence can effectively resist the externals.
Material: Low carbon steel wire Q195
Surface treatment:
Electric galvanized, hot dip galvanizing, spray, PVC coated, PE coated
Colours:
green, red, dark green, grass green, black, white, yellow, blue
applications:
the protection of Prison Fence is mainly used for prisons, post, border guards, fencing and
security areas, military defence and high-risk area
Features:
Anti-climb: Small openings - no toe or finger holds.
Anti-cut: robust wire and welded joints make cutting very difficult.
Better visibility: the flat, two-dimensional profile, easier to see through than chainlink
specifications:
MasterView 358
2.1m
2.4m
3.0m
Panel height
2134mm
2438mm
2997mm
Panel width
2515mm
2515mm
2515mm
Mesh size
12.7 x 76.2mm
12.7 x 76.2mm
12.7 x 76.2mm
Horizontal wire
4mm
4mm
4mm
Vertical wire
4mm
4mm
4mm
Panel weight
50kg
57kg
70kg
Posts
60 x 90 x 4 mm
60 x 90 x 4 mm
80 x 80 x 4 mm
Post length
2.8m
3.1m
4.0m
Clamp bar
40 x 6 m slotted
40 x 6 m slotted
40 x 6 m slotted
Fixings
8 security nuts
No. of fixings
8
9
11
Other specifications could be customed by the customers’ requirements.
Packaging:
Put the meshes and post on the tray, bind well with the strap, and then pack plastic film on the outside, prepare well for moisture proof, antitrust, preventing pieces bending. Or packaging according to customers’ requirements.
china wholesale ClearVu security fence spikes / Powder Coated security fence with spikeschina wholesale ClearVu security fence spikes / Powder Coated security fence with spikes
