Specifications
Brand Name :
LNF-Chain link Fence fabric
Model Number :
2.5" etc
Certification :
ASTM392 ASTM396
Place of Origin :
American Design China Made
MOQ :
500 liner meter
Price :
3.88$ per liner meter
Payment Terms :
TT30% deposit balance 70% at sight of finished products
Supply Ability :
10000 liner meters
Delivery Time :
7 work days
Packaging Details :
All metal Pallets
Materials :
Q235 steel
Color :
Any Ral Color
Treatment :
Hot Dipped Glavanized,Powder Coated
Mesh Opening :
50mm x 50mm ,55mm x 55mm ,75mm x 75mm ,60mm x 60mm ,80mm x 80mm
Diameter :
1.5mm to 5.00mm
Type :
Woven Mesh
Warranty :
5 -25 years depand on the treatment
Main Market :
Europea ,Middle East ,USA ,AU etc
Accessoires :
Tension Band ,Bar ,Steel Plate and Post Caps etc
Customized :
Available
Feature :
Diamond Mesh
Application :
Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence,and Son
Trade Mark :
N/M
Sample :
Free but pay freight cost
Nickname :
CYCLONE FENCE,wire netting, wire-mesh fence, chain-wire fence, cyclone fence, hurricane fence, or diamond-mesh fence
Description

Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting

Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting for Horse Fencing
Chain link type wire mesh nettings are high tensile flexible fence panels for barrier and protection uses. A kind of diamond opening woven wire mesh fence fabric. The spiral woven structure, the flexible and springy texture, together with the high tensile strength make galvanized steel chain link fence a high tensile steel fence. It is ideal for field fencing and horse fencing. The galvanized steel wire mesh fence fabric gives the fence linear strength and springy texture. It will absorb part of the force and protect horses from injury. The chain link barrier will also prevent predators from entering paddocks and pastures at the same time.
Features: Springy, flexible, high tensile.
Top Ends and Opening Shape: Two top ends applied for Chain link fence netting: barbed tape concertina or common knuckled end. Typical opening type of chain link fabrics is diamond shaped or rhombic mesh opening.
Supply Forms: Rolls or Cut Rolls. Chain link fabric is typically sold in 50' rolls. We will cut rolls to exact size for local deliveries and pick-ups only. Chain link is easily cut to size by removing one spiral link.
Major Finishes: Electro galvanized steel mesh fence; hot dipped galvanized; PVC coated galvanized. Most widely used spiral woven wire netting for fencing is galvanized steel and PVC coated galvanized steel chain links. Other materials like aluminum or stainless steel are also available.

Chain link fence is also known as diamond fence, it is woven with high-quality mild steel wire.

It has the features of woven simple, beauty and practical. Its finish treatment is galvanized and plastic coated with long-time use and corrosion protection.

They are widely used as protective fences in residential sites, roads, and sports fields.

Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting

Galvanized Chain Link Fence​ specifications

Chain Mesh Common Specifications
Fence Height: 5ft, 6ft, 8ft, etc. (1.5m, 1.8m, 2.0m, 2.4m, etc.)
Fence Length: 9m, 12m, 15m, 20m, 30m
Wire Thickness: 2.5mm, 3.0mm, 3.15mm, 3.5mm, 4.0mm
Opening size: 25x25mm, 50x50mm, 75x75mm, 80x80mm
Flat Bar: 25.0mm*5.0mm
Fence Post:
Round Post (dia. 48mm, 60mm, 75mm)
Clamps: Metal Clamps
Post Cap: Metal Rain Cap / Anti-UV PP Cap
Surface treatment: Pre-Hot Dipped Galvanized (100, 200, 250, 280g/m²)
PVC Coated (All colors in Ral)
Application
 Wire diameter
Line Post
 Top Rail
3’-4’ high 11 ga 1-5/8” 15 ga. 1-3/8” 17 ga.
5’-6’ high 11ga ,9ga 1-7/8” 16 ga. 1-3/8” 17 ga.
8'-10'high 9ga ,6ga 2-3/8” 15 ga. 1-5/8” 15 ga.

Galvanized Chain Link Fence​ type:

Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting

Galvanized Chain Link Fence​ usage:

This product is widely used in filters baskets, air filtration units,medicine ,building

cement, mechanical equipment protection, crafts manufacturing,high grade sound box nets, expressway fence,decorative ceilling,highway fence , walkway

Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting
Galvanized Steel and PVC Coated Galvanized Steel Chain Link Fence Netting
Learn more about Chain Link Wire Netting by Comparing:

How to choose chain link netting for your fencing uses: Electro Galvanized Steel Chain Link Netting or Hot Dipped Galvanized?
Material: Both Mild steel wire
Electro Chain Link Wire Mesh With 7-15G per Square Meter Zinc Coating;
Hot Dipped Galvanized Chain Link Wire Mesh With 35-400G per Square Meter Zinc Coating
Conclusion: Hot dipped fence netting consume much quantity of zinc and cost higher than galvanized steel chain links. At the same time, it offers stronger corrosion protection layer and serves a long time. So, choose electro galvanized wire netting fence for economic cost and the hot-dipped one for longer application demand.

Choose Welded Mesh or Chain Link for Your Fencing Netting: Comparing of Diamond Opening Chain Link Fence with Welded Mesh Fence:

Diamond hole woven wire mesh provides strong, durable and flexible construction. The closely spaced diamond mesh construction gives your fence linear strength and springy texture.
The welded wire fence has a welding spot will get breaking at great strength and it has a less springy texture.
Conclusion: Welded mesh fence is suitable for general fencing uses, while chain link fence is more suitable for sites that require fencing at the same time protecting, for example, zoos, animal breeding fencing, sports playground. The animals or people will not easily get hurt if they get in touch with the flexible chain link fences.

Applications:
As horse fencing and protecting fencing for animals:
Animal Breeding Fences
Veterinary Uses
Animal Training Fences
Zoos;
As General Safety Fencing:
Applications: Diamond mesh is used as fencing for sports field
Riverbanks, construction, gardens, and residence
Superhighway fences, railway fences, fencing for the airport, port, and other sites
AS fences to protect and support seawall, slope, road and bridge, reservoir and another civil engineering.
Equipment fencing;
As Protective Fencing for Sports:
Fences for playground and sports: Tennis, golf, football and various sports.
For pricing and sizing of our Chain Link Fence Netting, please contact us now.
