Specifications
Brand Name :
Diplomat Fence
Model Number :
Diplomat-1200mm-1500mm-1800mm-2100mm-2400mm
Certification :
AS/NZS1163& AS/NZS4506-1998
Place of Origin :
New Zealand And Australia Design
MOQ :
100
Price :
58.88$
Payment Terms :
TT 30% deposit balance 70% at sight of done cargo
Supply Ability :
3000
Delivery Time :
7 days
Packaging Details :
Metal Pallet With Plastic Jacket
Materials :
Q235
Color :
Black and Grey or other
Dimensions :
1800mm x 2400mm ,2100mm x 2400mm or Customized
Salt Spray Testing :
Pass
Treatment :
Powder Coated ,Hot Dipped Galvanized
Technical :
Punch Pipes and Welding etc
Nick Name :
Steel Fence ,Steel Tubular Fence ,Steel Spear Fence,Garrison Fence,ornamental steel fence
Upright Pipes :
25mm x 25mm x 1.20mm
Rails :
40mm x 40mm x 1.60mm
Post :
65mm x 65mm x 2.00mm x 3000mm
Popular :
Powder Coated Stain Black
Apllication :
Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence
Description

Spear Top Security Fence Diplomat Garrison Fencing Security Fencing 2.1m*2.4m fencing panels


We Promise the quality of our products
1). High quality galvanized steel tube with minimum 60g/square meter galvanization.
2). Silico bronze welded to make the welding seam extremely smooth and rust free any time.
3). Specially designed welding jig make all welding no deforming fence panel.
4). Sandblasting and phosphating before powder coating.
5). Akzo Nobel high-quality powder coating makes the fence panel long life.
Specification

Item No.

Panel Size (mm)

Rails (mm)

Pickets (mm)

Rail No.

BM15140

2100mm High X 2400mm Wide

40X40X2.5

25X25X2.0

2

BM15141

2100mm High X 2400mm Wide

40X40X2.0

25X25X1.6

2

BM15142

2100mm High X 2400mm Wide

40X40X1.6

25X25X1.2

2

BM15143

1800mm High X 2400mm Wide

40X40X2.5

25X25X2.0

2

BM15144

1800mm High X 2400mm Wide

40X40X2.0

25X25X1.6

2

BM15145

1800mm High X 2400mm Wide

40X40X1.6

25X25X1.2

2

BM15146

1500mm High X 2400mm Wide

40X40X2.0

25X25X1.6

2

BM15147

1500mm High X 2400mm Wide

40X40X1.6

25X25X1.2

2

Cap post 65X65mm (wall thickness 1.6mm - 3mm)

Cut length

Die Casting Bracket

Four holes


Our Products Win at the details
1. Our powder coating facility has totally 11 powder spray gun. Six guns are moving up and down both sides of the fence panel. Two fixed guns for the bottom rail at both sides and the other two fixed gun for the top rail at both sides. The last fun is always fixed at the position of spear top.
2. We will fo cross cut testing for the powder coating before delivery.
3. The QC of powder coating check the surface by light is the need. So any flaw of powder coating will be not escaped from the eye of QC.
4. Our QC check the powder coating thickness every position of the fence panel. The average thickness of the coating is more than 100um.
5. The package is extremely important for the powder coated fencing. We use heavy-duty steel frame package to well protect the good products. It will be very easy for our customers unload the pallets by forklift.
Spear Top Security Fence Diplomat Garrison Fencing Security Fencing 2.1m*2.4m fencing panels
Spear Top Security Fence Diplomat Garrison Fencing Security Fencing 2.1m*2.4m fencing panels
We have several types of fence that can be chosen by you.
Design service can be provided by our technical team.
Spear Top Security Fence Diplomat Garrison Fencing Security Fencing 2.1m*2.4m fencing panels
We have also other kinds of main products with high quality and reasonable price, feel free to contact us if you have any interest! Spear Top Security Fence Diplomat Garrison Fencing Security Fencing 2.1m*2.4m fencing panels

Our Factory
When our team start the business, we promise that we will make high quality with excellent service. During the past years, we have experienced hard price competition in local and world markets, but we have been keeping our faith and never surrender any quality. What we will do is providing our customer with high quality and reasonable competitive price. We understanding that customers' success makes us successful as well.
Our equipment is not the most advanced, but our experienced engineers make our facilities the most capable. With these facilities and hardworking workers, we have very high efficiency and low cost. Customers can just tell us your general idea, all other things you can trust our team. We are reliable and capable!
No matter you are wholesalers, distributors or final customers, we always have mutual benefit. We know how to build a long partnership with customers based on win-win cooperation.
World vision, international standards and local advantages, we will do better and better for our customers.

FAQ
1.
Q: Can you design for us?
A: Yes, our professional technology department can design for by our advanced software. Just send us your requirement in word or oral, we can do all other works for you.
2.
Q: We have a problem of spear crack from another supplier when forming the spears, do you have the same problem.
A: No, all spears are press-formed before aging, so no crack at sides of a spear.
3.
Q: What about the sample time and charge?
A: (1) 7-10 days if you want to customize your products. Free sample.
(2) 3-7 days if material available.
4.
Q: What about the delivery time of our products?
A: For standard fence panels, it needs 2 days to finish a full 40'HQ container. We have enough welder, so do not worry about the shortage of welders.
5.
Q: What is your MOQ for a trial order?
A: Normally, it needs a full container shipment for protecting fence panel during transportation. But we can talk about it.
