Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Conductive Copper Wire Mesh Screen 77um Micron Size 0.05-2.03mm Wire Diameter
Specifications
Brand Name :
TIANHAO
Model Number :
TH COPPER MESH
Certification :
ISO
Place of Origin :
HEBEI
MOQ :
1 kg
Price :
Price will be offered to you once get your detailed specification.
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300sqm/day
Delivery Time :
In stock, within 3-5 work days, no stock, 15-20work days. If have mold, 10-15days, if no mold, 20-30days.
Packaging Details :
1. inside use carton pipe for support+wire mesh layer+water proof paper 2.outside use plastic wooden bags, +wooden case/carton pipes/wooden pallets. 3.also we can as per your requirements.
NAME :
Conductive Copper Bronze Brass Woven Wire Mesh Screen Cloth
MATERIAL :
Copper Bronze Brass Wire
Weaving style :
Plain
mesh :
1-350 mseh
feature :
conductive
Application :
Shielding Copper Bronze Brass
Description

Conductive Copper Bronze Brass Woven Wire Mesh Screen Cloth

Product Description

Material type

Common material: Pure Copper,Brass, Phosphor Copper etc

Sepecial material:Tinned Copper etc
Wire diameter 0.05-2.03mm
Mesh count 1-200mesh
Micron size 77um(Min)
Weave style Plain woven,Twill woven,Dutch woven etc
Technique Woven
Feature EMF RF Shielding, Good Conductivity
Application Filter,Screening etc
Popular size 10mesh ,20mesh,50mesh 100mesh 150mesh 200mesh etc

1. Brass

> Material: Brass-65%,Zinc-35% and Brass-80%,Zinc-20%

Features: non-magnetic, wear- resistance and good ductility.

Uses: screening various granules, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.

2. Copper,Purple Copper

> Material: Pure Cooper-99.8%

Feature: non-magnetism and be able to bear the grind.

Uses: Purple copper wire mesh is widely used for filtrating electron beam and electron display screen.

3. Phosphor Bronze

> Material: Cu-85%-90%,the other 5%-15%

Features: non-magnetism and phosphor copper mesh can be able to bear the grind ache and alkali, good ductility.

Uses: screening various granules, powder, porcelain clay and glass, chinaware printing, filtering liquid and gas.

Mesh size

Mesh Wire Dia. Opening(mm)
SWG mm inch
6mesh 22 0.711 0.028 3.522
8mesh 23 0.610 0.024 2.565
10mesh 25 0.508 0.020 2.032
12mesh 26 0.457 0.018 1.660
14mesh 27 0.417 0.016 1.397
16mesh 29 0.345 0.014 1.243
18mesh 30 0.315 0.012 1.096
20mesh 30 0.315 0.0124 0.955
22mesh 30 0.315 0.0124 0.840
30mesh 32 0.247 0.011 0.573
32mesh 33 0.254 0.010 0.540
34mesh 34 0.234 0.0092 0.513
36mesh 34 0.234 0.0092 0.472
38mesh 35 0.213 0.0084 0.455
40mesh 36 0.193 0.0076 0.442
42mesh 36 0.193 0.0076 0.412
44mesh 37 0.173 0.0068 0.404
46mesh 37 0.173 0.0068 0.379
48mesh 37 0.173 0.0068 0.356
50mesh 37 0.173 0.0068 0.335
60mesh 37 0.173 0.0068 0.250
70mesh 39 0.132 0.0052 0.231
80mesh 40 0.122 0.0048 0.196
90mesh 41 0.112 0.0044 0.170
100mesh 42 0.012 0.004 0.152
120mesh 44 0.081 0.0032 0.131
140mesh 46 0.061 0.0024 0.120
150mesh 46 0.061 0.0024 0.108
160mesh 46 0.061 0.0024 0.098
180mesh 47 0.051 0.002 0.090
200mesh 47 0.051 0.002 0.076

RFQ:

1. Can you ship to my country?

We can ship to all the countries around the world via Express,Sea,Air.

2. How much is the shipping charge to my country?

The shipping charge depends on your located country and the weight of the package.

3 How long it will take for the shipping to my country?

Usually,it depends on the shipping company and the length of the shipping line.

4. How can I track the whole shipping process?

We will send you a tracking number.you can track the whole shipping process on the website.

5. How to OEM?

If you want OEM,please contact the sales department.We will get touch with you as soon as possible as we could.

6. What's payment?

TT,Western Union,Paypal(small order)

Our Services

* We are specialized in stainless steel wire filter mesh since 1980s

* We will keep update production process news for you during order.

* We will notice you in time if have any problem in production,and solve out that together.

* We will give you wonderful after sale service
