Low Carbon Iron Wire Mesh Gabion Plain Weave Style Long Durability Rust Proof
Low Carbon Iron Wire Mesh Gabion Plain Weave Style Long Durability Rust Proof
Specifications
Brand Name :
KAAP
Model Number :
KP2020011504
Certification :
ISO9001,SGS
Place of Origin :
Hebei,China
MOQ :
30 Square Meters
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
50000 Meter/Meters per Month
Delivery Time :
10-15 days
Packaging Details :
In roll, water proof paper in side and out side with woven bag;wooden case;pallet.
Material :
Low carbon iron wire, Stainless steel wire, Galvanized wire, Galvanized redrawing wire, Black steel wire.
Wire diameter :
0.5-5mm
Type :
Crimped Wire Mesh
Weave Style :
Plain Weave
Weaving :
Crimped before weaving, double crimped, single crimped
Feature :
Resistance against heat, acid, alkaline, corrosion, strength structure
Description

Crimped wire mesh specifications:


Diameter 1.0mm x mesh opening 8mm or 10mm
Diameter 1.5mm x mesh opening 12.5mm, 15mm or 20mm
Diameter 3mm x mesh opening 15mm, 20mm, 30mm
Length and width specifications: 1mX25m 1mX30m 1.2mX25m 1.2mX30m

Material

Iron wire, black wire, stainless steel wire 301, 302, 304, 304L, 316, 316L, 321, copper wire and other non-ferrous metal.

Weaving

Pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending.

Features

1) High tension: Much higher tension than common polyester mesh and smooth tension;

2) Super precision: Uniform wire diameter and aperture with extremely low difference;

3) Low elongation: Very small elongation of wire mesh at high tension;

4) High flexibility: The wire mesh will not lose elasticity at extreme tension;

5) High corrosion resistance: The excellent corrosion resistance of stainless steel wire exceeds polyester fiber;

Non-electrostatic: To avoid affects of non-electrostatic for print and ensure the safety of printing;

Good heat-melting resistance: Special features of stainless wire mesh. Suitable for heat-melting ink;

Good solvent resistance: To avoid the affects of any solvents to wire mesh and to ensure the safety of print screen.

Wire Gauge (SWG) Wire Diameter (mm) Mesh/Inch Aperture (mm) Weight kg/m2
6 4.8 1 20.6 11.5
8 4.05 2 9 16.5
10 3.2 2 10 10.5
12 2.6 3 5.9 10.5
14 2.0 3 6.5 6
16 1.6 4 5 5.5
17 1.4 5 5.1 5.0
18 1.2 5 4 3.6
19 1.0 6 3.2 3.0
21 0.8 7 2.8 2.3
22 0.7 8 2.5 2
