Specifications
Brand Name :
Hexie
Model Number :
UL3135 12AWG
Certification :
RoHS SGS UL
Place of Origin :
China
MOQ :
305 Meter
Price :
USD0.05-0.35 per Meter
Payment Terms :
T/T, Western Union, MoneyGram,PayPal
Supply Ability :
50000Meters per Month
Delivery Time :
3- 5 work days
Packaging Details :
PE bag with Carton
Product Name :
Flexible Silicone Cable UL3135 12AWG Electric Wire
Application :
UAV Robot Industrial Power Heater Lighting
Certificate :
UL RoHS SGS ISO9001
Conductor Material :
Tin-plated Copper
Insulator Material :
Silicone Rubber
Rated Voltage :
600V
Rated Temperature :
200℃
Standard :
UL758
Color :
Red Black Blue Yellow Green Brown Orange
MOQ :
305meters
Conductor No. :
19*0.47 or 65*0.254
Over Diameter :
3.92mm
Description

Flexible Silicone Cable UL3135 12AWG Electric Wire for New Energy Battery Wire Harness

Product Description


Place of Origin : China
Brand Name : Hexie
Model Number : UL3135 12AWG
Insulation Material : Silicone Rubber
Type : High Voltage
Application : Home Appliance, Lighting, Heater, Motor & Generator,
Conductor Material : Tinned copper
Jacket : Silicone Rubber, Silicone Jacket
Product name : Copper Core silicone Insulation Wire
Color : Red Black Blue Green Yellow Orange or Customized Color
Conductor : Tinned Copper
Insulation : Silicone Insulation Cable
Material : Silicone Copper
Rated Voltage : 600V
MOQ : 305M/Roll
Conductor Insulation Max.Conductor Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 Nominal Thickness
(mm)		 Diameter
(mm)		 (Ω/KM) (M)(Ft)
26 7/0.16 0.48 0.78 2.04 143 305/1000
24 7/0.20 0.61 0.78 2.17 89.3 305/1000
22 7/0.254 0.77 0.78 2.33 56.4 305/1000
20 7/0.31 0.94 0.78 2.5 35.2 305/1000
18 7/0.39 1.19 0.78 2.75 22.2 305/1000
16 7/0.49 1.49 0.78 3.05 14 305/1000
24 11/0.16 0.61 0.78 2.17 89.3 305/1000
22 17/0.16 0.76 0.78 2.32 56.4 305/1000
20 26/0.16 0.94 0.78 2.5 35.2 305/1000
18 41/0.16 1.18 0.78 2.74 22.2 305/1000
16 26/0.254 1.49 0.78 3.05 14 305/1000
14 41/0.254 1.87 0.78 3.43 8.78 305/1000
12 19/0.47 2.63 0.78 3.92 5.53 305/1000
0.30mm² 12/0.18 0.71 0.78 2.27 59.78 305/1000
0.50mm² 20/0.18 0.92 0.78 2.48 40.1 305/1000
0.75mm² 30/0.18 1.13 0.78 2.69 26.7 305/1000
1.00mm² 40/0.18 1.31 0.78 2.87 20 305/1000
1.25mm² 50/0.18 1.46 0.78 3.02 14.35 305/1000
2.00mm² 41/0.254 1.87 0.78 3.43 8.78 305/1000
2.50mm² 50/0.254 2.08 0.78 3.64 7.16 305/1000
