Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
Specifications
Brand Name :
Hexie
Model Number :
XT150 connector
Certification :
CE,ROHS
Place of Origin :
Guangdong
MOQ :
500 sets
Price :
$0.30~$5.0/set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal,Trade Insurance order
Supply Ability :
50000pairs per week
Delivery Time :
3-5working days after receive payement
Packaging Details :
waterproof bags and hard cartons
Product name :
RC lipo battery high current plug XT150 connector 6mm xt 150 for UAV motor drone
Application :
Vehicles & Remote Control Toys, RC Motor, Vehicles & Remote Co
Gender :
male and female
Color :
Red black blue
working frequency: :
low frequency
characteristic :
Flame retardant
Production technology: :
Injection molding
Description

RC Battery connector XT150 Connector Female Male Plug 6mm Gold Banana Bullet Connectors

  • Groove slot design of tail can contain 8-10awg silicone-line
  • Super inflaming retarding PA, high temperature resistance, make a longer life
  • 6.0mm lengthened and thicked gold plated banana plug, can be sustained a constant current 100A, 120A high current peak for 10 seconds
  • Housing can be merged and splited at any time, can be inserted and pulled separately, reduce the obstruction when inserted or pulled meanwhile, humanized design

  • Designed for currents up to 150 Amps
  • Ideal for those large scale electric projects
  • Low loss connectors are essential
  • Plastic case is detachable

  • High Current Connection: This connector can support Max.60A Continuous / Max.130A Peak Current.
  • High Grade Material: Brass with true gold plated, high strength insulated plastic housing is made from plastic PA also called Nylon.
  • Low Contact Resistance: 0.2mΩ, well designed spring structure on plug assures large contact surface and big contact force with socket.
  • Stable Connection: High stiffness spring structure on plug, very tight connection between plug and socket. Usage life time can reach 1,000 times Plug-in and Pull-out.
  • Safety: 500V DC rated voltage, anti-reverse polarity connection design, CE certificate.

item
value
Gender
Unisex
Age Range
13 Years & up
Place of Origin
China
Guangdong
Brand Name
Hexie
Model Number
XT150
Type
Other Outdoor Toys & Structures
Application
Romote Connector
Gender
male&female
Color
Red / Bule / Black
Rated Current
60A
Max. current
130A

Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable

Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable

Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable

Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable

Female Male Banana XT150 Battery Connectors 6mm Gold Bullet Durable
