Specifications
Brand Name :
Fortune Sky
Model Number :
BJ-880
Certification :
CCC,CE
Place of Origin :
China
MOQ :
1 Piece
Price :
USD1-USD9999
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram , Paypal
Supply Ability :
100 pcs per month
Delivery Time :
2-3 working days
Packaging Details :
carton or wooden box
Main Function :
Cut wire,both-ends stripping,intermediate strip, (wire twisting for BJ-880)
Cutting wire core :
0.1-4.0mm2 (30AWG-14AWG)
Processing Speed(decided by wire material) :
wire material) 2000-8000 pcs/hour
Cutting Length :
0.1-9999.9mm
Strip head :
1-30mm
Strip tail :
0.1-30mm
Description

This full or partial automatic wire stripping machine for stripping wire from 32AWG to 14AWG uses a hybrid drive microcomputer full LCD operating system, cutting, stripping, one time completion, but also the front half stripping with twisted wire, protect the integrity of the wire, special wire can instantly change the size of wire specifications.

Full or partial automatic wire stripping machine cut strip 20mm wire working vedios:

Full Or Partial Automatic Wire Stripping Machine Stripping Wire AWG32 To AWG18 Strip head:1 to 30mmFull Or Partial Automatic Wire Stripping Machine Stripping Wire AWG32 To AWG18 Strip head:1 to 30mm

Model No. BJ-600 BJ-650 BJ-800 BJ-880
Main Function Cut wire,both-ends stripping Cut wire,both-ends stripping,intermediate strip, (wire twisting for BJ-880)
Cutting wire core

0.1-4.0mm2

(30AWG-14AWG)

0.1-4.0mm2

(30AWG-14AWG)x2

0.1-2.0mm2

(32AWG-14AWG)x2

0.1-2.5mm2

(30AWG-14AWG)x2
Processing Speed(decided by wire material) 2000-8000 pcs/hour 4000-16000 pcs/hour 2000-8000 pcs/hour
Cutting Length 0.1-9999.9mm
No. Of Intermediate Stripping 0 13
Stripping Length

Strip head: 1-30mm

Strip tail: 0.1-15mm

Strip head: 1-30mm

Strip tail: 0.1-30mm

Strip head: 1-50mm

Strip tail: 0.1-30mm

Strip head: 1-30mm

Strip tail: 0.1-20mm
Accuracy of outlet inlet motor Mute hybrid stepping motor 0.1mm per stepping
Other functions Automatic wire inlet & outlet, timing
Driving Mode 4 wheels
Dimension(mm) 380x250x320 420x297x345 420x297x345 420x297x345
Net Weight 25 28 32 35
Blade Material Import Tungsten Steel/High speed steel
