JVT Wire to Board PCB 3.96mm Electrical Connectors Vertical with Friction Lock 2 Circuits Cross
JVT Wire to Board PCB 3.96mm Electrical Connectors Vertical with Friction Lock 2 Circuits Cross
JVT Wire to Board PCB 3.96mm Electrical Connectors Vertical with Friction Lock 2 Circuits Cross
JVT Wire to Board PCB 3.96mm Electrical Connectors Vertical with Friction Lock 2 Circuits Cross
Specifications
Brand Name :
JVT
Model Number :
JVT5001
Certification :
ISO9001/SGS/UL/ROHS/Reach
Place of Origin :
China
MOQ :
1000 PCS
Price :
Negotiation
Payment Terms :
T/T or Western Union
Supply Ability :
300000 per month
Delivery Time :
7-10 working days
Packaging Details :
PE bag packing +outer carton
Category :
PCB Headers
Application :
Power, Wire-to-Board
Orientation :
Vertical
Number of Rows :
1
Description

JVT Wire to Board PCB 3.96mm Pitch Connector Vertical with Friction Lock 2 Circuits Cross

3.96mm Pitch SPOX™ Crimp Housing, Female, with Friction Ramp, 2 Circuits

Datasheet (PDF) & Other Documents Download center:

1.JVT5001HXX-XX.pdf

2.JVT4001WN2-XXSN-D.pdf

Material Specification:

Terminal: Phosphor Bronze or Brass ,Tin plated

Housing: PA66,UL94V-0

Wafer: Nylon 66 UL94V-0

PIN: Brass ,Tin plated

JVT 3.96mm pitch Wire-to-Board PCB Header, Vertical, with Friction Lock, 2 Circuits,cross by molex 09-65-2038

Application Area:

Cell Phone

Table Computer

Lighting

Standard Specification:

Pitch

3.96mm

Poles

2-16

Applicable wire

AWG#18-22

Voltage rating

250V AC/DC

Current rating

5A AC/DC

Withstand voltage

1500V AC/minute

Working temperature

-25°C to +85°C

Insulation resistance

800MΩ Min

Contact resistance

20MΩ Max

Our advantage

Favorable unit price

Strict quality control

Shortest lead time

Professional team( from Tool esigning stamping,Injection molding assembling,Testing to packing)
Accelerated equipments:10 automated injection molding
20 automated pin - setting
6 high precision stamping machines

Payment Details:

Payment Terms:T/T or Western Union

Minimum Order:1000 Pieces

Primary Competitive Advantages:

  • Service
  • Country of Origin
  • Experienced Staff
  • Guarantee/Warranty
  • International Approvals
  • Price
  • Prompt Delivery
  • Quality Approvals

Main Export Markets:

  • Asia
  • Australia
  • Central/South America
  • Mid East/Africa
  • North America
