Specifications
Place of Origin :
Anhui, China
Brand Name :
WNK
Model Number :
WNK805
Packaging Details :
each product in one inner paper box with foam protection
Supply Ability :
2000 Set/Sets per Week low cost differential pressure sensor
Price :
$45.00 - $65.00/Pieces
MOQ :
1pcs
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Delivery Time :
5-8 work days
Warranty :
1 YEAR
Customized support :
OEM, ODM
Measured media :
liquid, gas and steam
Output signals :
4~20mA, 1-5V
Accuracy :
0.2%F.S, 0.5%F.S
Pressure range :
-100KPa~6MPa
Protection class :
IP65
Ex-proof :
ExiaII CT4/CT6, ExidIICT6
Housing material :
304SST
Power Supply :
10.5-55V DC, 10.5-30V DC
Keywords :
pressure sensor/low cost differential pressure sensor
Port :
Shanghai port
Description
4-20mA Low Cost Water Pressure Sensor / Pressure Transducer

WNK805 Gauge/Absolute Pressure Transmitter (Diffused silicon sensor)

WNK805 integral pressure transmitter adopts stainless steel shell structure, built in stainless steel oil filled sensor, intelligent digital circuit with precise temperature characteristic compensation, it can be used reliably and stably, it is suitable for gas, liquid, steam pressure measurement and pressure measurement with corrosive media.

WNK805 Gauge/Absolute Pressure Transmitter (Diffused silicon sensor)
Applicable media
Liquid, Gas, Steam
Pressure measurment
Gauge Pressure, Absolute pressure, Negative pressure, Sealing pressure
Pressure range
0-0.2~-100kPa, 0-0.2~1000kpa, 60mPa
Output signals
4~20mA, 1-5V for optional
Accuracy
0.2, 0.5
Stability
±0.25% FS/year
Zero drift
50% of full range span.
Max overload
200% of sensor range
Display
LED (Optional)
Housing material
304 stainless steel
Mechanical connection
M20×1.5; 1/2-18NPT, 1/4NPT, Customize
Power supply
Non-explosion: 10.5~45V DC
EEX ia:10.5~30 V DC
Ambient temperature
-40~85℃
Process temperature
-40~85℃
Product Show


WNK805 Water Pressure Transducer 4-20mA Stainless Steel ShellWNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell
WNK805 Water Pressure Transducer 4-20mA Stainless Steel ShellWNK805 Water Pressure Transducer 4-20mA Stainless Steel ShellWNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell

WNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell
Hot Product

WNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell

Company Information

WNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell

Exhibition

WNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell

Certification

WNK805 Water Pressure Transducer 4-20mA Stainless Steel Shell

FAQ

Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
