Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Panel Furniture Abs Wood Edge Banding Machine Auto Two Glue Pot 13m Min
Specifications
Brand Name :
HOLD
Model Number :
HQ520
Certification :
CE
Place of Origin :
Guangdong China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
LC/ TT
Supply Ability :
10 Set / Month
Delivery Time :
45 Days
Packaging Details :
Poly Wrapping Or Wood cases
Total Power :
17.6kw
Overall size :
6050x900x1750mm
Feeding Speed :
12.5-18-24(m/Min)
Edge thickness :
0.4~3(mm)
Panel thickness :
10~60(mm)
Panel length :
≥120(mm)
Min.sheet size :
120*100(mm)
Panel width :
≥100(mm)
After-sales service provided :
Video technical support,Field maintenance and repair service,Field installation,commissioning and training
Type :
Automatic electric
Control system :
Delta Inverter,computer servo motor,PLC automatic control,PLC
Voltage :
220V/380V/440V/415V
Working pressure :
0.7Mpa
Pressure Beam :
Electrical lifting
Description

High-Quality Finish Edge Banding Machine With Two Glue Pot For Panel Furniture Factory HQ520

Features

This machine was specially designed for the Fullhouse modular cabinet production.

1. Adopt imported motor and high quality electrical component.
2. High precision and work efficiency.
3. Automatic and precise gluing procedure as well as integrated double finish.
4. Glue evenly, conveying stability.
5. All the working area and specifications can be customized according to your requests.

Base informations

Thickness of banding
0.4-3mm
Width of banding
10-60mm
Thickness of workpiece
10-60mm
Heating power
1.5kw
Feeding motor power
2.2kw
Glue post motor
0.37kw
End trimming motor
0.55*2 kw
Fine trimming motor
0.75*2 kw
Polishing motor
0.18*2 kw
Feeding speed
13m/min
Air pressure
0.7Mpa
Workpiece length
>=100mm
N.W.
3200kg
Overall dimension
6050x900x1750mm


About our company

One-stop solution for interior furniture equipment and wooden door equipment

HOLD Machinery was founded in 2004, focusing on the development of a full range of furniture machinery equipment and wooden door machinery and equipment, providing furniture and wooden door enterprises with solutions for whole factory planning and automatical production lines, providing customers with excellent quality, efficient and stable products, and high-quality service.

HOLD Machinery has served the majority of furniture and wooden door enterprises in more than 40 countries and regions around the world and has won wide admiration from customers.


FAQ:

1. Do you have the machine in stock?
Sorry, we don't have the machine in stock, edge banding machine has many options such as voltage, speed, function, and so on, So it's hard to prepared samples.

2. How long is your delivery time?
For our standard model, the delivery time is around 1.5~2 months. For the customized model, the delivery time is around 2~3 months. It depends on the client's project and quantity.

3. Do you have a factory?
Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
