1) it can press 2-8mm diameter biomass fuel pellet, animal feed and fertilizer pellets ,
2) Raw biomass materials can be waste from sawdust, rice husk, agricultural stalk, straw, peanut shell, sun flower, paper ect
,animal feed materials can be grain, soybean, maize ect, fertilizer materials can be animal manure and so on .
3) Small pellet mill can press high density pellets , for biomass , density can reach 1.1-1.4ton/m3, diameter can be adjusted from
2-8mm , there is knive installed nearby the outlet door, which can adjust pellet length
4) when small pellet mill works, it is flat die rotates and then take rollers work, but the whole roller assemble is stable . in
this way will keep all materials piles up in the center of die , increase machine capacity and pelletizing efficiency.
Model | Power(kw) | Output(kg/h) | Weight(kg) | Packing Size(mm) |
SKJ2-200A | 7.5 | 80-120kg/h | 350 | 1000*450*850 |
SKJ2-250A | 15 | 200-250 | 560 | 1400×600×1000 |
SKJ2-300A | 22 | 250-300 | 800 | 1550×650×1000 |
SKJ2-350A | 30 | 300-500 | 900 | 1600×800×1300 |
SKJ2-450A | 45 | 600-800 | 1500 | 1800×800×1500 |
SKJ3-550A | 55 | 800-1200 | 1600 | 1900×800×1700 |
