Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Specifications
Condition :
New
Type :
Panel Saw
Use :
Woodworking, Wood Cutting, Wood Plate Slotting
Style :
Horizontal
Place of Origin :
Shandong,China
Brand Name :
TEING
Usage :
Woodworking, Wood Cutting, Wood Plate Slotting
Voltage :
380V/50HZ/3PH, Or Customized
Dimension(L*W*H) :
2800*1100*900mm
Warranty :
12 Month
Application :
Furniture Factory, Woodworking Factory, Home Use, Manufacturing Plant, Building Material Shops, Machinery Repair Shops, Construction Works
Weight (KG) :
650 KG
Power (kW) :
4KW+0.75KW/5.5KW+1.1KW
Key Selling Points :
High-accuracy
Max.Cutting Height at 90°(mm) :
80 mm
Max.Cutting Height at 45°(mm) :
55 mm
Max. Length of Workpiece (mm) :
2700 mm
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Marketing Type :
Hot Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Motor
MAX. Cutting width :
1250MM
Saw blade Diameter :
300MM
Scoring saw blade diameter :
120MM
Main saw spindle speed :
3000/4000/5000 rpm
Scoring saw spindle speed :
7000/8000 rpm
Spindle saw diameter :
30 mm
Scoring spindle saw diameter :
20 mm
Keyword :
Woodworking Machine
Dimensions sliding table :
2800x375 mm
Name :
Precision Panel Saw
Packaging Details :
Export Standard Plywood Case
Port :
Qingdao, China
Supply Ability :
2000 Set/Sets per Year
Price :
$2,200.00/sets 1-4 sets
Description
Product Overview
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Technical Data Sheet
Model
WSN2845
Dimensions sliding table
2800x375 mm
MAX. Cutting length
2700 mm
MAX. Cutting width
1250 mm
Saw blade Diameter
300 mm
Scoring saw blade diameter
120 mm
Max. Cutting Thickness
80mm
Main saw spindle speed
3000/4000/5000 rpm
Scoring saw spindle speed
7000/8000 rpm
Spindle saw diameter
30 mm
Scoring spindle saw diameter
20 mm
Tilling saw blade
0-45°
Main motor power
4 KW/5.5KW
Scoring motor
0.75KW/1.1KW
Weight
650 KGS
Voltage
380/220V or customizied
Main balde up and down
Manual
Overall dimensions
2800*1100*900 mm
Details Images
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Product packaging
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Exhibition
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Company Profile
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Wood Working Sliding Table Panel Saw WSN2845 with Precision and Max.Cutting Height at 90°
Qingdao Skyyi Hengtong Machinery Equipment Co.,Ltd is one of the leading manufacturer in the woodworking machinery of China. We have 10000sqm factory and well-known "TEING" brand of sliding table saw, edge banding machine, sanding machine and so on.
With more than 10 years in woodworking machine industry, our machine had sold out to more than 20 Chinese Province, and more than 30 countries and regions, such as: Vietnam, Malaysia, USA, Canada, Brazil, Preu, Pakistan, Russia, Ukraine, India, Uzbekistan, Israel, Yemen, Thailand, Mexico, Ecuador and so on.
We passed the ISO 9001:2008, SGS and other certification, we believe through our efforts to make "TEING" grow up to world famous brand in order to serve worldwide woodworking industry with our quality products.
