Product Manual: 4-022-03-0116 Position Indicator

Product Overview

The 4-022-03-0116 Position Indicator, also known by its part number 4022030116, is a precision-engineered spare part designed for use in Homag woodworking machines. This position indicator is a crucial component for ensuring accurate positioning and alignment of various machine parts, facilitating precise and efficient operations. The model TYP DA04-04-4.00-E features a D=14H7 dimension, making it suitable for high-precision applications in complex woodworking machinery.

Applications

This position indicator is used in a range of Homag woodworking machines. Its primary function is to provide accurate feedback on the position of machine components, which is essential for tasks that require precise alignment and positioning. This ensures high-quality outcomes in woodworking processes, including cutting, shaping, and finishing.

Features

- Precision Design: The position indicator is designed with high accuracy to ensure reliable feedback on the position of machine components. Its D=14H7 dimension indicates a highly precise fit, suitable for applications where exact alignment is crucial.

- Durability: Made from robust materials, the position indicator is built to withstand the demanding conditions of woodworking environments, including exposure to dust, vibrations, and temperature variations.

- Compatibility: The 4-022-03-0116 Position Indicator is compatible with various Homag machine models, ensuring seamless integration and reliable performance across different types of woodworking machinery.

- Ease of Use: The position indicator is designed for straightforward installation and maintenance, minimizing machine downtime and enhancing operational efficiency.

- Reliable Operation: With its precision engineering, the position indicator ensures consistent and accurate positioning feedback, critical for maintaining high-quality production standards in woodworking processes.

Installation Instructions

1. Safety First: Ensure the machine is powered off and disconnected from the power supply to prevent accidental activation during installation.

2. Access Position Indicator Location: Open the relevant access panels or covers to reach the position indicator mounting area.

3. Remove Old Position Indicator: If replacing an existing indicator, carefully remove it by loosening the mounting screws or bolts. Keep these fasteners for securing the new position indicator.

4. Prepare the New Indicator: Verify that the new 4-022-03-0116 Position Indicator matches the required specifications, including the D=14H7 fit.

5. Install New Indicator: Insert the new position indicator into the designated slot, ensuring a precise fit. Align it correctly to avoid misalignment and inaccuracies.

6. Secure the Indicator: Use the original screws or bolts to secure the new position indicator in place. Ensure all connections are tight but do not over-tighten to avoid damaging the component.

7. Test Operation: Power on the machine and check the new position indicator for accurate feedback. Ensure there are no discrepancies or alignment issues.

8. Close Access Panels: After confirming proper installation and function, close any opened access panels or covers securely.

Maintenance

Regular maintenance of the position indicator is crucial for optimal performance:

- Inspection: Periodically inspect the position indicator for signs of wear, damage, or misalignment. Look for any deviations that could affect its accuracy.

- Cleaning: Keep the indicator and surrounding areas clean from dust and debris. Use a soft brush or cloth to gently clean the component without damaging it.

- Calibration: Ensure the position indicator remains calibrated. Recalibrate periodically as per the machine's maintenance schedule or after any significant adjustments.

- Replacement: Replace the position indicator if it shows signs of excessive wear, damage, or if it no longer provides accurate feedback.
