10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass
Specifications
Brand Name :
DALU
Model Number :
BXS-M
Certification :
GB/T 19001-2016/ISO 9001:2015
Place of Origin :
CHINA
MOQ :
0.5 Tons
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
20 Tons
Delivery Time :
6 weeks after down payment
Packaging Details :
exporting wooden case
Product Name :
Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift
Product Color :
Brown
Application :
winch and windlass brake, hoist brake, crane brake, winder brake, drilling machine brake
Size :
10, 15, 20 meters/roll
Material :
brass wire, resin, viscose,
Type :
BXS-M
woven :
woven brake lining asbestos free woven brake lining rolls
resin :
melamine resin
main raw material :
non-asbestos yarns
color :
yellow
Description

Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift

Ningbo Xinyan Friction Materials Co., Ltd. is a professional manufacturer of non asbestos woven brake lining. Our advantage is that we also produce raw materials of non-asbestos yarns, then weave into brake lining by ourself, so that we have the whole cost and quality control.

Non-asbestos Woven Brake Lining selects new-type abrasion resistant and high temperature resistant non-asbestos yarns which contain brass wires, viscose fiber, Glass fiber, Aramid fiber etc.

We adopt Japanese Technology. All yarns are woven by advanced Japanese loom machinery & equipment then impregnate into specially formulated polymer resin, through high temperature, low temperature etc. processing workmanship.

10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass


10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass

Temperature Coefficient of friction(μ) Wear rate(v)(cm³/N.m)
100℃ 0.35~0.65 ≤0.7 x 10-7
150℃ 0.35~0.65 ≤1.1 x 10-7
200℃ 0.30~0.60 ≤1.5 x 10-7
250℃ 0.25~0.60 ≤2.5 x 10-7

10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass

Quick Detail:Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift


Model: BXS-M Non-asbestos Woven Brake Lining
Material: Viscose fiber, Aramid fiber, glass fiber, 2 brass wires, Melamine resin.
Working Conditions: 250℃,Static Pressure: 4.0Mpa
Applied field: It is widely used for braking deceleration and transmitting power of big power machineries.
Specification: T(5~30)x W(≤500)mm ; Available Length: 10m,15m,20m

Description:Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift

Non-asbestos Woven Brake Lining selects new-type abrasion resistant and high temperature resistant non-asbestos yarns which contain brass wires, viscose fiber, Glass fiber, Aramid fiber etc.

Our product owns high performance of wear resistance, low wear rate, high tensile strength, good softness, high temperature resistance, corrosion resistance, oil resistance, long service life and impact resistance etc. They are definitely 100% non-toxic, pollution free and environmental products.

Brake Lining is extensively used in marine and industrial applications. It is suitable for
winch and windlass, hoist, crane, winder, drilling and workover rigs, agricultural
vehicle, elevator, and construction machinery.

10 15 20m Asbestos Free Woven Brake Lining Roll For Anchor Windlass



Specifications:Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift

Competitive Advantage:Anchor Windlass Resin Asbestos Free Woven Brake Lining Roll For Tractor Winch Lift

Our factory could produce the raw materials for brake lining. We have yarn machines, we produce yarns and then weeve yarns into brake lining rolls by ourself, so that we could control the whole quanlity and cost very well.

Our factory has 6 weaving machines and work with many customers around the world. I will make the quotation list for you after getting your detail size and qty.

Please send us inquiry by email or wechat/whatsapp me at (86) 13771895935 to get more informations
