100hp Rotary Screw Type Compressor 460V 380V With G2 Pipe
100hp Rotary Screw Type Compressor 460V 380V With G2 Pipe
Specifications
Brand Name :
WOYO
Model Number :
HSD
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 unit
Price :
To be confirmed
Payment Terms :
T/T
Supply Ability :
100 unit/Month
Delivery Time :
10-30 days
Packaging Details :
PLYWOOD CASE
Warranty :
2 year for airend, 1 Year for spare parts
Power :
100hp
Working pressure :
0.7-1.3Mpa
Air Capacity :
9.1-12.2M3/min
Voltage :
208-220/460V, 60HZ & 380V 50HZ
Type :
Screw
Description

Screw Air Compressor, Direct Drive, 100hp, 380V50HZ, 220V60HZ

1, High reliability, less parts, no wearing parts, so it is reliable operation, long life, the general screw airend design life of 30 years.

2. Convenient operation and maintenance, high degree of automation, operators do not need to go through a long period of professional training, to achieve unattended operation.

3. Good power balance, no unbalanced inertia force, the machine can work smoothly at high speed, to achieve no foundation operation.

4. Strong adaptability, with the characteristics of forced gas transmission, volume flow is almost not affected by exhaust pressure, in a wide range of working conditions can maintain high efficiency, in the compressor structure without any change, suitable for a variety of working conditions, so easy to finalize the batch production.

Model

Power(KW)

Pressure(MPa)

Capacity(m3/min)

Pipe Diameter

Weight (kg)

Dimension(mm)

HSD10

7.5

0.8-1.3

0.7-1.1

G1/2

180

960*650*850

HSD15

11

0.8-1.3

1.0-1.7

G3/4

300

1000*750*1000

HSD20

15

0.8-1.3

1.6-2.3

G3/4

320

1000*750*1000

HSD30

22

0.8-1.3

2.7-3.4

G1

420

1070*850*1260

HSD40

30

0.8-1.3

3.1-5.0

G1

450

1070*850*1260

HSD50

37

0.8-1.3

4.7-6.4

G1 1/2

600

1200*1000*1390

HSD60

45

0.8-1.3

5.7-7.2

G1 1/2

700

1200*1000*1390

HSD75

55

0.8-1.3

6.7-9.4

G2

920

1700*1200*1550

HSD100

75

0.8-1.3

9.1-12.2

G2

950

1700*1200*1550

HSD125

90

0.8-1.3

11.4-15.2

G2

1350

2100*1300*1650

HSD150

110

0.8-1.3

14.5-19.9

DN80

2650

2500*1650*1900

HSD180

132

0.8-1.3

16-23

DN80

2850

2500*1650*1900

HSD220

160

0.8-1.3

21-27

DN80

4100

3000*1900*1950

HSD250

185

0.8-1.3

23-30

DN80

4300

3000*1900*1950

HSD270

200

0.8-1.3

25.5-32.5

DN100

5300

3600*2200*2200

HSD300

220

0.8-1.3

28.8-38

DN100

5500

3600*2200*2200

More than 40 years of experience in theory and practice of screw compact unit, the engineers of WOYO focus on special screw airends and modules of green intelligent screw air compressor R&D and manufacturing. For saving energy, reducing emission and protecting environmental,create more value for customers in three aspects. More green protection for the Earth.

Save the environment, ensure to provide better services and solutions, save costs for users, and seek the largest growth space. The main purpose is to protect and save energy, stimulate the growth of economic productivity, comply with market demand, save energy and reduce environmental pollution.
