Specifications
Brand Name :
Wolvesteam
Model Number :
WT700207
Certification :
CE,FCC
Place of Origin :
USA
MOQ :
1 pcs
Price :
negotiated price
Payment Terms :
L/C, D/P, T/T, Western Union,Paypal
Supply Ability :
2000 pcs per years
Delivery Time :
3-4 weeks
Packaging Details :
Dimension: 640×540×550 mm Weight: 75 Kg
Type :
Bomb Jammer
Jamming Area: :
50-800 meters
Signal Jammer for :
20 - 6000MHz Cell Phone Signal Jammer
Working Time :
24 Hours/365days Continuously
Antenna Type Options :
Directional Or Omnidirectional Antennas Option
Dimension :
640×540×550 mm
Weight :
75 Kg
Packing :
Box
Description

Military RF Signal Vehicle Bomb Jammer 5G All Cell Phone Signal Jammer With DDS Convoy Jamming System

Product description :

This device is not only bomb jammers, but also high power portable DDS convoy jamming system,portable RF jammer,portable vehicle bomb jammer. This jammer can implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.

It can cove all RF communication Frequencies between 20MHz to 3600MHz continuously and simultaneously.

Features:

1. High-power portable multi-band jammer.
2. Field programmability for rapid adjustment frequence with output Watt.
3. Modular construction for easy maintenance,repair and upgrade.
4. Jammer up to five different jamming modules simultaneously,and cover up to 10 different frequency bands.
5. Each module with LED display to show its working frequency ,output power and etc.
6. 250-300 watt total RF output power.
7. Equipped with a remote control unit. The operator can ON/OFF each module through the wired remote controller.
8. Fully portable trolley-type case.
9. Internal battery, AC mains or DC power.

Technical Specifications:

11 bands for option: The frequencies can be from 20-6000MHZ

Output Interface

Frequency Range

 Out Power

RF Output dBm

CH1

20-108MHz

Wireless ,FM Radio

100W

CH2

135-174MHz

 Wilkie-talkie(VHF)

100W

CH3

300-400MHz

 Remote Control, Drone

100W

CH4

400-470MHz

 Wilkie-talkie(UHF),Car alarm

100W

CH5

851-894MHz

 CDMA

100W

CH6

925-960MHz

 GSM

100W
CH7 1570-1580MHz GPSL1 50W

CH8

1805-1920MHz

 DCS,PCS

100W

CH9

2110-2170MHz

 WCDMA

50W

CH10

2400-2485MHz

 WIFI,Drone,Bluetooth

50W

CH11

5725-5850MHz

WIFI,Drone

15W

Jamming Radius:

50-800M, the jamming radius still depends on the strength signal in given area

HS Code:

8543709200

Total output power:

600~1200W
Power Consumption: 330W

Type:

Vehicle Jammer

Dimension:

640×540×550 mm

Packing:

Neutral Packing

Signal Jammer for:

20 - 6000MHz Cell Phone Signal Jammer

Power supply:

AC110 240V

Weight: 75 Kg
Humidity: 5%-95%
Working Temp: -20℃ to +55℃

RF Characteristics:

RF Characteristics Description
Output Power 915 Watts
Internal Modulation FM Hopping Frequency
Signal Source VCO Synthesized
Power Supply AC110-240V,24V or 48V DC
Modules Per Unit 11
Contol ON/OFF with Switch
Monitoring Adjusted output power by DIP switch
Antenna External- Omni-directional for 360°
Power Amplifier Protectors Full VSWR Protector
Operating Hours Unlimited

Terms and conditions:

Delivery Time Schedule

Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.

Payment Terms

40% advance, 40% after one month,20% before shipping.

Terms of Delivery

FOB HONGKONG/ USA.

Warranty

36 months.

Software Updates

Free software updates will be provided for a period of 36 months.

Extended Warranty

After 4th Year : 5% of total for each years.
