Specifications
Brand Name :
wolvesteam
Model Number :
WT600184
Certification :
CE
Place of Origin :
China
MOQ :
1 piece
Price :
negotiated price
Payment Terms :
L/C, T/T
Supply Ability :
100pieces/month
Delivery Time :
25 days
Packaging Details :
Dimension (not including antennae): 30*45*15cm, Weight:15kg
Packing :
Box
HS Code :
8543709200
Jamming Range :
50-150 Meters
Type :
Backpack Jammer
Weight :
15 kg
Frequency Bands :
6 Bands
Antennae type :
External high gain Omni directional Antenna
Application Area :
Military Units, Prison, Police, Bomb Disposal
Switch Control :
Manually
Output power :
80 watt
Description

Military High Power EOD Backpack GSM 3G 4G 5G Cell Phone Signal Jammer Manpack RF Jammer

Product Description

1,High Power Freqeuncy Scan Convoy Jamming System, implementing the most effective and reliable RF jammer technology and equipped with a fully-integrated broadband jamming system. This is highly portable and light weight.
2,It plays an important role to use the heavily loaded vehicle and backpack type devices in some extreme hard situation.The operator can carry it forward through the hills and muddy road, as well as Climbing steep mounts and stairs avoid casualties and improve the combat efficiency.
3,This is full manpack multi band Jamming system is designed with a ruggedized case, light weight, highly mobility and reliance. This device is configured with 6 different jamming modules, the jamming frequency can be more than 8 Bands. Jamming frequency module can be up to 120 watt output power maximum.
4,It is especially easy to install and operate: simply attach the selected antennas and activate the desired frequency bands. The general design of the system meets military requirements as well as international quality standards and requirements. Our industrial in-house quality management system guarantees highest quality standards in terms of performance, reliable and long-life cycles.

Features:

  1. Specially used for anti-terrorism,EOD,bomb-disposal,force filed work,etc;
  2. Large coverage for 6 channels frequencies and other customized output;
  3. Backpack design for portable carry and flexible operation.Specially applicable for emergency,transitions, temporary control requirements;
  4. Built-in efficient rechargeable battery can be used for 2 hours after fully charged;
  5. Camoflage customized backpack convenient to install and operate;
  6. Metallic paint chassis box,pressure-resistant and durable;
  7. Built-in efficient cooling fans and cooling fin ensure the product work stable in a long service time.

Specifications:

Output Interface Output Frequency
CH1 -CDMA: 851-960MHz /-GSM: 925-960MHz
CH2 -DCS: 1805-1880MHz
CH3 -PCS: 192-1990MHz
CH4 -3G: 2110-2170MHz
CH5 -4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)
CH6 -4G LTE: 725-770MHz(US) or 790-826MHz(EU)
Jammed Signal Freqency: CDMA,GSM,2.4G WIFI,5.8G WIFI,GPS L1,GPS L2-L5,VHF,UHF....
Type: Backpack jammer
Output Channel: 6 output channels
Power Consumption: Max: 220W
Output power: 80watt
Parameter Shielding Range: Radius 50-150 meters (-75dBm,depending on the distance of base station in an open filed)
Jammer Module Number 6
HS Code: 8543709200
Packing: Box
Dimension (not including antennae): 30 *45 *15cm
Technical Parameters:
Net Weight 14kg
Total Weight 15kg Aviation Case included
Ambient Temperature -10ºC - +50ºC
Relative Humidity ≤80%
Power Consumption ≤360W
Power Input AC100~240V,DC24V
Battery 24V,30AH,Built-in standby battery
can used for 90~180 minutes
Antenna Parameters Omni antennas,gain:4~5dBi
Switch Control Manually
Equipment Chassis Metallic Paint
Cooling system Active "smart" with integrated incoming air filter
Antennae type: External high gain Omni directional Antenna

Terms and conditions:

Delivery Time Schedule Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank.
Payment Terms 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc.
Terms of Delivery FOB HONGKONG/ USA.
Warranty 36 months.
Software Updates Free software updates will be provided for a period of 36 months.
Extended Warranty After 4th Year :5% of total for each years.
