Specifications
Brand Name :
XDK
Model Number :
Fiber Optic Patch Cord SC/APC-SC/APC,G652D, Simplex
Certification :
ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS
Place of Origin :
China/Vietnam
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5-8 work days
Packaging Details :
regular packaging
Supply Ability :
5 million termination/month
Fiber Mode :
G652D
Connector Type :
SC/APC-SC/APC
Fiber Count :
Simplex
Jacket Material :
LSZH, PVC( customized)
Color :
Yellow
Length :
1m,5m(can be required)
Description

Fiber Optic Patch Cord/SC/APC-SC/APC Singlemode G652D/ Simplex/3.0mm/ LSZH/PVC/ Yellow

Features

1) Avalible in simplex, duplex connector options

2) Quick-tum service for fast delivery

3) TIA compliant color-coded connectors and boots

4) Cable jaket and boots color-coded for easy ID of fiber

5) Insertion loss and return loss are 100% tested

6) Other jacket colors available as custom with MOQ and lead time applicable

G652D Fiber Optic Patch CableG652D Fiber Optic Patch CableG652D Fiber Optic Patch Cable

Introduction

Fiber optic patch cords suited for equipment jumper cable, cross connects and work area connections. All patch 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards.

Our patch cord provides high reliability and flexibility for our customers in different industries. All patchcords can be customized in length, fiber mode and connector types to suit every single customer requirement with our state-of-art production facilities.

Specification

Connector Type SC/APC-SC/APC Fiber Count Simplex
Fiber Mode G652D 9/125um Working Wavelength 1260~1625nm
Insertion Loss ≤0.3dB Return Loss ≥60dB

Attenuation at 1310/1550nm

(Typical)

 0.36/0.22 dB/km Ferrule Material Ceramic
Cable Diameter 3.0mm Strength Member Aramid yarn

Minimum Bend Radius

(Long term)

 10D

Minimum Bend Radius

(Short term)

 20D
Cable Jacket PVC or LSZH Cable Colour Yellow
Operating Temperature -20~70°C Storage Temperature -40~85°C

Our certificates
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH
