Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua
Specifications
Brand Name :
XDK
Model Number :
Fiber Optic Patch Cord ST/UPC-ST/UPC Multimode OM3, Simplex
Certification :
ISO9001, IEC-61754, TIA/EIA-604, GR326, RoHS
Place of Origin :
China/Vietnam
MOQ :
negotiable
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
5-8 work days
Packaging Details :
regular packaging
Supply Ability :
5 million termination/month
Fiber Mode :
OM3 50/125um
Connector Type :
ST/UPC-ST/UPC
Fiber Count :
Simplex
Jacket Matericl :
LSZH, PVC( can be required)
Jacket Color :
Aqua
Length :
1m or 5m(customized)
Description

Fiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ AquaFiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ AquaFiber Optic Patch Cord/ST/UPC-ST/UPC Multimode OM3/ Simplex/3.0mm/ LSZH/PVC/ Aqua

Introduction

Fiber optic patch cords suited for equipment jumper cable, cross connects and work area connections. All patch 100% factory tested to ensure performance to TIA/EIA-568-B-3 standards. FC, SC, ST, LC Patch Cords are available in both multimode and single mode cable-types, in duplex and simplex versions.

Features

1) Avalible in simplex, duplex connector options

2) Quick-tum service for fast delivery

3) TIA compliant color-coded connectors and boots

4) Cable jaket and boots color-coded for easy ID of fiber

5) Fiber options: OS2, OM1,OM3, and OM4

6) 100% tested for insertion loss and return loss

Specification

Connector Type ST/UPC to ST/UPC Fiber Count Simplex
Fiber Mode OM3 50/125um

OFL Bandwidth

(850/1300nm)

 1500/500 MHz*km
Insertion Loss ≤0.3dB Return Loss ≥35dB

Attenuation at 850/1300nm

(Typical)

 3.5/1.5 dB/km Ferrule Materials Ceramic
Cable Diameter 3.0mm Strength Member Aramid yarn
Cable Jacket LSZH or PVC Cable Colour Aqua
Operating Temperature -20~70°C Storage Temperature -40~85°C

Our certificates
1) ISO9002
2) SGS, ROHS
3) ULE329066
4) REACH
