XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
XDK OS2 G652D 3.0mm 12 / 24 Core MPO Breakout Cable
Specifications
Brand Name :
XDK
Model Number :
12C-MPO
Certification :
CPR, DCR,ECR,FCR,ROHS,ISO9001
Place of Origin :
China / Viernam
MOQ :
10 pcs
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
5 million termination per month
Delivery Time :
5-8 working days
Packaging Details :
OEM PE bag, carton box, wooden roll
Product name :
12 / 24 Core MPO Breakout Cable
Material :
LSZH / PVC
Color :
Yellow, Aqua, Pink, Violet, Customized
Fiber mode :
OS2 G652D
Cable size :
3.0mm
Connector type :
MPO to MPO/MPT, LC, LC uniboot, CS
Description

XDK MPO Breakout Cable OS2 G625D 3.0mm 12 / 24 Core Fiber Cable

Description:

MPO/MTP fanout/breakout cables are the ideal connection to patch panels and data distribution routing. They can be made with both 12 fiber MTP connectors and 24 Fiber MPO/MTP connectors. A variety of options are available and include MPO/MTP to LC, SC, ST, and FC fiber optic patch cables.

Performance:

END A END B
Connector Type MTP/MPO MTP/MPO LC LC Uniboot SC
Polarity Polarity A, Polarity B, Polarity C
IL(MTP/MPO) Standard ≤0.5 dB Ave ≤0.3dB
IL(MTP/MPO) Elite: ≤0.35dB Ave: ≤0.2dB
IL(LC/SC) Standard ≤0.25dB Low Loss : ≤0.15dB
RL SM:≥60dB MM: ≥20dB
Tester Brand EXFO & JGR
Repeatability ≤0.2dB
Interchangeability ≤0.2dB
Mating 1000 Times
Opterating Temperature -20℃ ~ +70℃
3D Interferometer Fiber Height: 1000nm~3500nm
Radius Long: 500mm min Radius Short: 50mm min Ferrule Height: 7.95mm min
MM Core Dip: <100nm

Note:

Each MPO Breakout Cable is available with 8 to 144 fibers and is most commonly used to assist in upgrading existing 10G networks to higher performing 40G and 100G rates. Higher performing options are available and include the Senko MPO Plus® Premium Connector and Corning® ClearCurve® Fiber, able to create less insertion loss and preserve the connection integrity.

Features:

- Ulitize MPO/MTP connectors

- Inner: Ceramic Ferrule

- Available in Elite insertion loss and standarad insertion loss.

- Low loss elite versions are offered, featuring low insertion loww for demanding high speed networks where power budgets are critical.

- They use a simple push-pull latching mechanism for easy and intuitive insertion and removal.

- It provides up to 8, 12, 16, 24 times the density, thereby offering savings in circuit card and rack space.

- Available in OS1/2, OM1, OM2, OM3 and OM4, OM5

- Telcordia’s GR-326-Core, IEC Standard
- Green Production, RoHS Standard

- Interface polished type has PC, UPC and APC

Application

- Metro

- CATV

- Passive fiber optic networks

- Builing communication center

- Bank Data center

- Communication center rooms
- FTTH (Fiber to The Home)

- FTTA (Fiber to the attena)
- LAN (Local Area Network)
- FOS (fiber optic sensor)
- Fiber Optic Communication System
- Optical fiber connected and transmitted equipment

- Defense combat readiness

Packing:

According to Stardard Export Packing.

Carton box, wooden box, wooden pallet.

Shipping:

- International express such as UPS, TNT, DHL, etc

- Internatioal air: CA, AA, EA, etc

- By sea

Tag: fiber optic breakout cable, breakout fiber optic cable, qsfp breakout cable
