Specifications
Brand Name :
XF-FLANGE
Model Number :
BLIND,WN,THREADED,SO
Certification :
PED, ISO9001
Place of Origin :
CHINA
MOQ :
3TON
Price :
USD 1260-1200 TON
Payment Terms :
L/C, D/P, T/T
Supply Ability :
2500 TON MONTH
Delivery Time :
10-40DAYS
Packaging Details :
PLYWOOD CASE OR PALLET
Technical :
FORGED
Standard :
DIN2576/2502/2503
Size range :
1/2"-56"
Type :
WN,SO,THREADED,BLIND
Pressure :
PN6/PN10/PN16/PN25/PN40/PN63/PN100
Material :
S235JR/P245GH/P250GH/P280GH
Surface :
Raise Face
Usage :
GAS or Petrolem
Color :
Rust proof oil
Package :
Plywood case or pallet
Steel :
Carbon steel, Stainless steel
Certificate :
ISO9001,PED
Built :
Since 1986
Description

DIN2576 Flange DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Forged S235JR P250GH P245GH

The product range below:

1.Carbon steel pipe fitting

· Kind: Elbow /Tee /Reducer /Cap

· Size: 1/2"-72"

· Material: ASTM A234 WPB

· Thickness: SCH10-SCH160 /STD/XS/XXS

· Standard: ASME B16.9 / B16.28 / B16.25

2.Carbon steel flange (Forged and cast)

· Kind: WN /SO /PL /BL/LJ

· Size: 1/2"-104"

· Material: ASTM A105,SS400,RST37.2,Q235,16Mn,20#,20Mn,S235JR,P245GH,P265GH,P280GH and so on.

· Standard: ASME B,GOST,EN1090-1,DIN,BS4504,AWWA,SABS1123,UNI.

3.Stainless steel pipe fitting

· Kind: Elbow /Tee /Reducer /Cap

· Size: 1/2"-72"

· Material: 304/304L,316/316L.

· Thickness: SCH10-SCH160 /STD/XS/XXS

· Standard: ASME B16.9 / B16.28 / B16.25

4.Stainless steel flange(forged and cast)

· Kind: WN /SO /PL /BL/LJ

· Size: 1/2"-104"

· Material: A182 F304/304L,F316/316L,316Ti,321,317L.

· Standard: ASME B,GOST,EN1090-1,DIN,BS4504,AWWA C207,SABS1123,UNI.

FLANGES DIN / EN
Type Norm Nominal Pressure Dimension
Welding Neck Flange EN1092-1 Typ11 PN6-PN400 DN10-DN2000
DIN 2631 - DIN 2638
Blind Flanges EN1092-1 Typ05 PN6-PN400 DN10-DN2000
DIN 2527
Flat Flanges for welding DIN 2573 PN6-PN40 DN10-DN2000
DIN 2576
EN1092-1 Typ01
Loose Flange + Weld-on Collars DIN2642 PN10-40 DN10-DN2000
EN1092-1 Typ02
EN1092-1 Typ32
Loose Flange + Weld Neck Collars DIN 2673 PN10-PN40 DN15-DN2000
EN1092-1 Typ04
EN1092-1 Typ34
Threaded Flanges EN1092-1 TYP13 PN10-PN40 ½“-6“
Materials: P250GH/C22.8, P265GH, 16Mo3, 13CrMo4-5, 10CrMo9-10, P355N, P355QH1, 1.4301, 1.4307, 1.4404, 1.4541, 1.4571, 1.4462, 1.4539
FLANGES ASME / ASTM / ANSI
Type Norm Class Dimension
Welding Neck Flanges ASME B16.5 150lbs – 2500lbs ½“-48“
ASME B16.47 Serie A
ASME B16.47 Serie B
BS3293
Blind Flanges ASME B16.5 150lbs – 2500lbs ½“-48“
ASME B16.47 Serie A
ASME B16.47 Serie B
BS3293
Slip On Flanges ASME B16.5 150lbs – 300 lbs ½“-24“
Materials: A105, C21, 316/316L, 304/304L, A350 LF2

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

DIN EN1092-1 TYPE01 DIN2502 PN16 DN200 Din 2576 Flange Forged S235JR P250GH P245GH

a) How can I get more details about your products?

You can send an email to our email address. We will provide catalogue and pictures of our products for your reference.We can also supply pipe fittings, bolt and nut, gaskets etc. We aim to be your piping system solution provider.

b) How can I get some samples?

If you need, we will offer you samples for free, but new customers are expected to pay express charge.

c) Do you provide customized parts?

Yes, you can give us drawings and we will manufacture accordingly.
