Specifications
Brand Name :
XF-FLANGE
Model Number :
SO FLANGE
Certification :
ISO,PED
Place of Origin :
China
MOQ :
1ton
Price :
USD 1340-1510 TON
Payment Terms :
D/P, L/C, T/T
Supply Ability :
2500 ton per Month
Delivery Time :
25-40days
Packaging Details :
Plywood case or pallet
Standard :
ANSI B16.5
Pressure :
150LBS,300LBS,600LBS,900LBS,1500LBS,2500LBS
Stainless steel :
A182 F304/304L,F316/316L
Size :
DN15-DN2000
Type :
WN,SO,THREADED,BLIND
Material :
Carbon steel A105
Color :
Black,Yellow
Usage :
Connection the pipe
Certificate :
ISO, PED
Output :
2500ton/month
Technology :
Forged
Payment item :
30% advance payment,70% against BL copy
Location :
Hebei Province
Package :
Plywood case or pallet
Application :
petroleum and Gas
Description

WN Flange ANSI B16.5 B16.47 SO Blind Threaded LJ SW ASME A105 150LBS A182 F304 F316

HEBEI XINFENG is a leading manufacturer who is specialized in stainless steel seamless pipes , We has the most advanced producing and testing equipment . We can totally satisfy your requirement.

FORGED FLANGE

1) ANSI B16.5, ASME B16.5/B16.47 FLANGE

Size range: 1/2" to 80" DN15 to DN2000

Design: welding neck, slip on, blind, socket welding, threaded, lap-joint

Pressure: 150#, 300#, 600#,900#,1500#, 2500#

Wall thickness for welding neck flange: STD, SCH40, SCH80, SCH160. SCHXXS

Material: Carbon steel A105, Stainless steel 304/304L, 316/316L

Coating: black paint, yellow transparent paint, cold and hot dip galvanize

2) EN1092-1 FLANGE

Size range: DN15 to DN2000

Design: type01 plate flange, type02 loose flange, type05 blind flange, type11 welding necking type12 slip on flange, type 13 threaded flange

Pressure: PN6, PN10, PN16, PN25, PN40, PN64, PN100

Material: Carbon steel C22.8, S235, S235JR, P235GH, P245GH,P250GH,P280GH,P265GH.Stainless steel: 304/304L, 316/316L

Coating: black paint, yellow transparent paint, cold and hot dip galvanize

3) DIN FLANGE

Size range: DN15 to DN2000

Design: slip on flange DIN2573,2576,2502,2503, 2543,2545

welding neck falnge DIN2631, 2632,2633,2634,2635

blind flange DIN 2527 PN6, PN10, PN16, PN25, PN40

threaded falnge DIN2565,2566,2567,2567

loose flange DIN 2641,2642,2656,2673

Material: Carbon steel ST37.2/S235JR,C22.8. Stainless steel 1.4301, 1.4404

4) GOST FLANGE

Size range: DN15 to DN 2000

Design : plate falnge 12820-80, welding neck flange 12821-80

Pressure: PN6, PN10, PN16, PN25, PN40

Material: Carbon steel CT-20. Stainless steel 304/304L, 316/316L

Coating: rust-proof oil, cold and hot galvanize

5) JIS B2220 FALNGE

Size ragne : 15A to 2000A

Design: SOP, BIND, SOH,

Puressure: 1K, 2K, 5K, 10K, 16K, 20K, 30K, 40K

Material: Carbon steel SS400, Stainless steel SUS304, SUS316

Coating : rust-proof oil, cold and hot galvanize

PRODUCT INTRODUCTION:

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
SIZE 1/2″ (15 NB) to 48″ (1200NB)
CLASS/ PRESSURE 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
DIN DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
Flange Face Type Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Standard ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Surface pickling, annealing, bright, sandblast, hairline
Test Certificates EN 10204/3.1B
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc
Type: Plate Flange, Flat Flange, Slip on Flange, Welding Neck Flange, Long Welding Neck Flange, Blind Flange, Socket Welding Flange, Thread Flange, Screwed Flange, Lap Joint Flange
Connection Type Raised Face, Flat Face, Ring Type Joint, Lap-Joint Face, Large Male-Female, Small Male-Female, Large Tongue, Groove, Small Tongue, Groove.
Production Grade ASTM A182 F 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316L, 316Ti, 316L, 317, 317L, 321

Product information:

Flange is the parts which connects two pipe ends, flange connection is defined by the flange, gasket and bolt three are connected as a group of combined sealing structure of the detachable connection. The gasket is added between the two flanges and then fastened by bolts. Different pressure flange, thickness is different, and the bolts they use are different, when pump and valve connect with pipe, the parts of the equipment are also made of the corresponding flange shape, also known as flange connection, usually closured bolted connection parts are also known as flanges, such as the connection of ventilation pipe, this kind of parts can be called "flange type part", but this connection is only part of a device, such as the connection between flange and water pump, it's not inapposite to call water pump as flange type parts,but relative small valve,it can be called as flange type parts .

Product Pictures:

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

Material Detail:

MECHANICAL PROPERTIES 力学性能 MECHANICAL PROPERTIES 力学性能
Standard C Mn P S Si Cu Ni Cr Mo Tensile Strength Yield Strength Elongation Reduction of Area Hardness
碳 锰 磷 硫 硅 铜 镍 铬 钼 抗拉强度 屈服强度 延伸率最小 面收缩率 硬度
% % % % % % % % % Mpa Mpa % % HB
A105 ASTM A105 MIN% 0.60 0.10 485 250 22 30
MAX% 0.35 1.05 0.035 0.040 0.35 0.40 0.40 0.30 0.12 187
A350LF2 ASTM A350 MIN% 0.60 0.15 485 250 22 30
MAX% 0.30 1.35 0.035 0.040 0.30 0.40 0.40 0.30 0.12 655 197
F304 ASTM A182 MIN% 8.00 18.00 515 205 30 50
(1.4301) MAX% 0.08 2.00 0.045 0.030 1.00 11.00 20.00 215
F304L ASTM A182 MIN% 8.00 18.00 485 170 30 50
(1.4307) MAX% 0.03 2.00 0.045 0.030 1.00 12.00 20.00 215
F316 ASTM A182 MIN% 10.00 16.00 2.00 515 205 30 60
(1.4401) MAX% 0.08 2.00 0.045 0.030 1.00 14.00 18.00 3.00 215
F316L ASTM A182 MIN% 10.00 16.00 2.00 515 205 30 60
(1.4404) MAX% 0.03 2.00 0.045 0.030 1.00 14.00 18.00 3.00 215
F321 ASTM A182 MIN% 9.00 17.00 515 205 30 50
MAX% 0.08 2.00 0.045 0.030 0.75 12.00 19.00

2016 Dusseldorf Tube

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

2015 OTC

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

2018 Dusseldorf Tube

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

Working Ispection:

DN15 To DN 2000 Flange WN ANSI 150 SO Blind LJ SW ASME A105 A182 F304 F316

COMPNAY INTRODUCTION

HEBHEI XINFENG HIGH-PRESSURE FLANGE AND PIPE FITTING CO., LTD ( XINFENG) was founded in 1988, specializing in the manufacture of forged flanges and pipe fittings. Located in Mengcun Hui Nationality Autonomous Region, known as the base for manufacture of elbows and pipe fittings in China, XINFENG enjoys a pleasant environment and convenient transportation, with Beijing and Tianjin city to the north and the Bohai Sea to the east.

XINFENG was licensed with independent export entitlement in 2006 and now its products are mainly for oversee markets, exported far to South Korea, Russia, countries and regions in middle-east, southeast Asia, south America and west Europe. These products are widely used in the fields of petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, and well received with praise and trust by customers from home and abroad, wining the company a very good reputation.

With a new stance, we hope to tighten our relationships with customers from both abroad and domestics on the purpose of mutual benefit and development for our prosperous future. Warmly welcome customers to us for friendship and business negotiation.

FAQ

Q1. Can I have a sample order for stainless steel Flanges products?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?
A:Sample needs 3-5 days;

Q3. Do you have any MOQ limit Flanges products order?
A:3ton

Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping was also optional. For mass products, ship freight is preferred.

Q5. Is it OK to print my logo on products?
A: Yes.

Q6: How to ensure quality?
A: Mill Test Certificate is supplied with the shipment. If needed, a Third Party Inspection is acceptable
