ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
Specifications
Brand Name :
XF
Model Number :
1/2"-72"
Certification :
ISO,PED
Place of Origin :
CHINA
MOQ :
1PCS
Price :
1USD-100USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
1500TONS one month
Delivery Time :
15-30days
Packaging Details :
Plywooden cases and Pallets
STANDARD :
DIN2605/1 EN10253-1 ISO 3419
Material :
A234 WPB ST37.2 P265GH A182 F304/304L,316/316L
SIZE :
1/2"*72"
Coating :
Oil , Hot galvanized , Cold galvanized
Load port :
XINGANG , TIANJIN CHINA
Usage :
GAS Or Petrolem
Description

DIN2605/1 EN10253-1 ISO 3419 STEEL BUTT WELDING FITINGS ELBOW TEE REDUCER CAP

Material :A234 WPB ST37.2 P265GH A182 F304/304L,316/316L

Size:1/2"-72"

Coating:Oil , Hot galvanized , Cold galvanized

Package:Plywood Cases And Pallets

We can supply a complete range of butt weld fittings to BS EN 10253-2:2007, these seamless fittings are all made of carbon steel to BS EN 10216-2 and were previously known as BS 1965 welding fittings. All of our EN 10253-2 butt weld fittings are "Type B" meaning they're suitable for use at full service pressure, you'll normally find medium and heavy grades in this range to match the dimensions of the BS EN 10255 (BS1387) tube that these fittings are normally used with.

FITTINGS Steel Pipe Elbow
Technique Hot-pushing, welding
Standard ASME B16.9, GOST 17375-2001, GOST 30753-2001, EN 10253
Size DN 15-DN 2400, 1/2" - 96"
Thickness SCH 20, STD, SCH 40, SCH60, XS, SCH 80, SCH 160, XXS
2MM-32MM
1.6MM-customized
Pipe Elbow Ends Beveling
Type LR pipe elnow
SR pipe elbow
45 degree pipe elbow
90 degree pipe elbow
60 degree pipe elbow
180 degree pipe elbow
customized degree pipe elbow
Surface Treatment Black Painting, Transparent Anti-rust Oil, Sand Blast
PE/3PE anti-corrosion coating, other customized coating
Material A234-WPB, steel 20#, A420-WPL6, WP304L, WP316L, WP304, WP316, etc..
Material in Stock Carbon steel, Mild steel, LTCS, Alloy Steel
Package Plastic bags, pallets, plywood case, etc
Production Time 3-5 days for stock goods, 15-30 days for one container,
more 10 days for one more container.
Application Petroleum, Natrual Gas, Water Disposal, Shipbuilding, Nuclear Energy,
Chemical Engineering, Deckle, Electric Power

EN 10253-1 Reducers Dimensions Schedule

Check 2.3 mm to 4.5 mm EN 10253-1 Grade S235 elbow dimensions and price list.


ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee

Side D Side D1 Length
DN D T DN D1 T1 L
25 33.7 2.6 20 26.9 2.3 35
32 42.4 2.6 20
25		 26.9
33.7		 2.3
2.6		 51
39
40 48.3 2.6 20
25
32		 26.9
33.7
42.4		 2.3
2.6
2.6		 67
55
38
50 60.3 2.9 25
32
40		 33.7
42.4
48.3		 2.6
2.6
2.6		 77
61
50
65 76.1 2.9 32
40
50		 42.4
48.3
60.3		 2.6
2.6
2.9		 95
84
63
80 88.9 3.2 40
50
65		 48.3
60.3
76.1		 2.6
2.9
2.9		 108
86
56
100 114.3 3.6 50
60
80		 60.3
76.1
88.9		 2.9
2.9
3.2		 143
114
90
125 139.7 4.0 65
80
100		 76.1
88.9
114.3		 2.9
3.2
3.6		 159
135
88
150 168.3 4.5 80
100
125		 88.9
114.3
139.7		 3.2
3.6
4.0		 189
141
94
200 219.1 6.3 100
125
150		 114.3
139.7
168.3		 3.6
4.0
4.5		 210
170
130
250 273.0 6.3 125
150
200		 139.7
168.3
219.1		 4.0
4.5
6.3		 250
220
130
300 323.9 7.1 150
200
250		 168.3
219.1
273.1		 4.5
6.3
6.3		 290
215
130
350 355.6 8.0 150
200
250
300		 168.3
219.1
273.1
323.9		 4.5
6.3
6.3
7.1		 335
255
125
100
400 406.4 8.8 200
250
300
350		 219.1
273.1
323.9
355.6		 6.3
6.3
7.1
8		 330
250
175
130

ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee

ISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing TeeISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing TeeISO 3419 Stainless Steel 304 Buttweld Fittings DIN2605-1 EN10253-1 Butt Weld Reducing Tee
