BS 4504 PN10 PN16 PN25 PN40 Standard Blind Flange
BS 4504 PN10 PN16 PN25 PN40 Standard Blind Flange
Specifications
Brand Name :
XF
Model Number :
XinFeng Flange
Place of Origin :
Hebei . CHINA
Certification :
ISO9001.PED
MOQ :
1Ton
Price :
negotiable
Packaging Details :
PLYWOODEN CASES / PALLET
Delivery Time :
15-45 DAYS
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
1000-5000 TONS/MONTH
Connection Type :
Welding Neck, Slip On, Blind, Socket Welding, Threaded
Application :
Petroleum, Chemical, Power, Gas, Metallurgy, Shipbuilding, Construction, Etc.
Flange Type :
WN,SO,PL,BL,SW,LF/SE,TH
Certificate :
ISO, CE, API, BV, Etc.
Process :
Forged
Package :
Wooden Cases, Pallets, Etc.
Size :
DN15-DN2000, DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN2000
Sealing Surface :
RF,FF. Black Paint, Yellow Paint,transparent Paint, Cold And Hot Dip Galvanize
Description

BS 4504 Standard Blind Flanges: Precision Components for Pressure Applications

1. Product Description: BS 4504 Standard Blind Flanges are specialized flanges designed to provide a sealed end in pressure systems and pipelines. These flanges are manufactured to meet the British Standard 4504, which ensures their quality and reliability for various industrial applications. They are available in different pressure ratings, including PN10, PN16, PN25, and PN40, to suit a range of operating conditions.

2. Product Parameters:

Parameter Description
Type Blind Flange (also known as Blank Flange)
Sizes Customizable based on nominal pipe size (NPS)
Specifications As per client requirements or standard dimensions
Standard BS 4504
Material Carbon Steel, Stainless Steel (e.g., 304, 316), or other alloys
Surface Treatment As-forged, galvanized, painted, or coated with anti-corrosive material

3. Mechanical Properties:

Property Typical Requirements
Tensile Strength Typically above 400 MPa, depending on material grade
Yield Strength Typically above 240 MPa
Elongation ≥20% for most material grades
Hardness Varies depending on heat treatment and material grade

4. Pressure Ratings:

Pressure Class Description
PN10 10 bar (145 psi)
PN16 16 bar (232 psi)
PN25 25 bar (362 psi)
PN40 40 bar (580 psi)

5. Chemical Composition:

Element Typical Range (%) for Carbon Steel Typical Range (%) for Stainless Steel 304 Typical Range (%) for Stainless Steel 316
Carbon 0.15 - 0.30 ≤0.08 ≤0.08
Manganese 0.50 - 1.60 ≤2.00 ≤2.00
Phosphorus ≤0.045 ≤0.045 ≤0.045
Sulfur ≤0.045 ≤0.030 ≤0.020
Silicon ≤0.30 ≤1.00 ≤1.00
Chromium - 18.0 - 20.0 16.0 - 18.0
Nickel - 8.0 - 10.5 10.0 - 14.0

6. Product Uses:

  • Pressure Vessels: Used to close off the ends of pressure vessels.
  • Piping Systems: Ideal for creating a closed or "blind" end in a pipeline.
  • Industrial Plants: Employed in various industrial plants for maintenance and testing purposes.
  • Machinery and Equipment: Utilized in machinery that requires flanged connections.

7. Product Grade Standards:

  • BS 4504: The flanges are manufactured in compliance with the British Standard 4504, which specifies the requirements for steel flanges for pressure purposes.

Conclusion: BS 4504 Standard Blind Flanges are versatile and robust, offering a reliable solution for pressure applications where a sealed or closed end is required. Their adherence to BS 4504 ensures that these flanges are manufactured to high standards of quality and safety, making them suitable for a wide range of industrial uses.

BS 4504 PN10 PN16 PN25 PN40 Standard Blind FlangeBS 4504 PN10 PN16 PN25 PN40 Standard Blind Flange
