Specifications
Brand Name :
HOLDONE
Model Number :
YLV
Certification :
CCC FCC CE
Place of Origin :
China
MOQ :
1000 m
Price :
USD1-USD10
Payment Terms :
T/T
Supply Ability :
10km/month
Delivery Time :
10 working days
Packaging Details :
carton/ wood or metal drum
Application :
Overhead
Conductor material :
Aluminum
Type :
Low Voltage,High Voltage,Medium Voltage,AAC AAAC ACSR ACAR
Insulation material :
bare,No
Jacket :
No
Description

10kv 33kv Aluminum Conductor ABC Aerial Bundle Cable XLPE Insulated 11kv Overhead Power Aluminum Cable 3x95mm

Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Holdone
Model Number:
aerial bundled conductor cable
Insulation Material:
XLPE PVC PE
Type:
Medium Voltage
Application:
Self Support Aerial Cable
Conductor Material:
Aluminum/Copper
Jacket:
PE/XLPE/PVC
Conductor:
ACSR/AAC/AAAC
Hot-Sale Size:
70mm 90mm 185mm 150mm
Cores:
1(single core)/3(triplex)
Code Name:
According to the srandard
Standard:
IEC/SIP/NFC33209 and so on
Packing:
Wooden Drum Iron Drum As your request
Certificate:
ISO9001/CCC
MOQ:
1000m as usuall
OEM:
Yes
Product name:
XLPE Insulated 11kv Overhead Power Aluminum Cable

Specification and Parameter of MV ABC Cable

6.35/11kV & 12.7/22kV ABC Cable-AS/NZS 3599.1 Standard
number of cores x nominal cross section Nominal conductor diameter Nominal insulation thickness Nominal insulation screen thickness Nominal sheath thickness AAAC/1120 support conductor size Nominal overall diameter Weight Continuous current rating, A
Still air 1m/s wind 2m/s wind
mm^2 mm mm mm mm No/mm mm kg/km A A A
6.35/11kV
3x35 6.9 3.4 0.8 1.2 7/4.75 52.4 1370 110 155 185
3x50 8.1 3.4 0.8 1.2 7/4.75 54.6 1530 130 185 225
3x70 9.7 3.4 0.8 1.2 7/4.75 57.8 1790 160 235 280
3x95 11.4 3.4 0.8 1.2 7/4.75 61.3 2100 195 285 345
3x120 12.8 3.4 0.8 1.2 19/3.50 67.3 2540 230 335 405
3x150 14.2 3.4 0.8 1.2 19/3.50 70.1 2840 255 380 460
3x185 15.7 3.4 0.8 1.2 19/3.50 73.1 3190 295 440 530
12.7/22kV
3x35 6.9 5.5 0.8 1.2 7/4.75 61 1780 110 155 180
3x50 8.1 5.5 0.8 1.2 7/4.75 63.3 1970 130 185 220
3x70 9.7 5.5 0.8 1.2 7/4.75 66.5 2260 160 230 275
3x95 11.4 5.5 0.8 1.2 7/4.75 69.9 2600 195 285 335
3x120 12.8 5.5 0.8 1.2 19/3.50 75.9 3070 225 330 395
3x150 14.2 5.5 0.8 1.2 19/3.50 78.7 3390 255 375 450
3x185 15.7 5.5 0.8 1.2 19/3.50 81.7 3760 290 435 520
