1.Quick Details
Place of Origin: Henan, China (Mainland)
Brand Name: ZHENGLAN
Insulation Material: XLPE
Type: Low Voltage
Application: Construction
Conductor Material: Copper/Aluminum
Jacket: PVC
Insulation color: Red, yellow, green all according to clients demand
Number of cores: 5cores
Rated voltage: 0.6kv/1kv
Packaging Details: fully wooden drum, steel wooden drum, fully steel drum or customized

2.Application
Laying in the room, tunnels, cable trenches and pipes, can also be buried in loose soil, the cable can not withstand mechanical external force. Single-core cable is not allowed to lay in the magnetic pipe. Used for power station, industry, switch gear and urban power supply network.

3.Product Standard
Basic design to IEC 60502-1, IEC 60228
China: GB/T 12706.2-2008
Other standards such as BS7870,DIN and ICEA upon request

Characteristics:
XLPE insulated power cable features mechanical strength, aging, environmental stress and chemical resistance, available for working under high temperature condition for long.

4.Technology Property
1)The long-term permissible operation temperature of the conductor shall not be higher than 70℃.
2) Conductor maximum short circuit((less than 5 second) temperature shall not be higher than 160℃.
3) The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0℃.
4) Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardance.
5) Light weight, perfect bending properties, installed and maintained easily and conveniently.

Why Choose Zhenglan Cable:

• OEM/ODM services provided
• Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
• Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
• Registered capital of $30 million and factory covers an area of 60,000㎡
• Advanced test equipment and procedures, 100% inspection before factory
• Enough stocks and the higest efficient shipping time guarranteed
• Professional pre-sales and after-sales services provided


  Model	Description
  YJV(YJLV)	Copper(Aluminum) core XLPE insulated PVC sheathed power cable
  YJV22(YJLV22)	Copper(Aluminum) core XLPE insulated steel tape armoured and PVC sheathed power cable
  YJV32(YJLV32)	Copper(Aluminum) core XLPE insulated steel wire armoured and PVC sheathed power cable
  ZR-YJV(ZR-YJLV)	Copper(Aluminum) core XLPE insulated flame retardant PVC sheathed power cable
  ZR-YJV22(ZR-YJLV22)	Copper(Aluminum) core XLPE insulated steel tape armoured and flame retardant PVC sheathed power cable
  ZR-YJV32(ZR-YJLV32)	Copper(Aluminum) core XLPE insulated steel wire armoured and flame retardant PVC sheathed power cable

•
