Specifications
Place of Origin :
China
Brand Name :
SECUSCAN
Certification :
CE, ISO
Model Number :
AT6550B
MOQ :
1
Packaging Details :
Wooden Packing
Delivery Time :
7 days when we have stock,15 days when we have no stock
Payment Terms :
L/C,T/T
Supply Ability :
300 sets/month
Warranty :
12 months
Technical Support :
free of all life
OEM :
Yes
Tunnel size :
650*500mm
Penetration :
typical 40mm
Wire resolution :
38-40mm
Penetration resolution :
34mm
Generate angle :
80 degree
Generate power :
0.4-1.2mA
Generate voltage :
160kv
Conveyor max load :
170kgs
Price :
Negotiable
Description

Computed Tomography X Ray Scanning Machine with High Resolution

Ultra clear scanning images X-ray Baggage Scanner Model: AT6550B

------Special for hotel and Metro baggage inspection

Quick Details

General Specification

Tunnel Size: 650(W)*500(H)mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 170kg
Wire Resolution: 32AWG to 40AWG

Spatial resolution:

 horizontal:1.3 or 1.0mm,
vertical: 1.3 or 1.0mm
Penetration: 38 to 40mm Steel

Film Safety:

 Guarantee ISO1600 Film
X-ray Leakage: <1 μSv/h (at a distance of 5cm
from external housing)
Pass rate: 720 bags per hour

Installation Data

Operation temperature/Humidity: 0℃-45℃/20%-95%(non-condensing)
Storage Temperature/Humidity: -20℃-60℃/20%-95%(non-condensing)
Operation Power: 220VAC(±10%)50±3Hz
Power Consumption:
1.0 KW (max), 0.7KW(working)
Noise: <58db

X-ray Generator

Beam direction: Diagonal Diagonal
Generate angle: 80 degree
Anode Voltage: 140Kv or (100Kv to 160Kv adjustable)
Anode power: 0.4 to 0.5mA
Cooling / Duty Cycle: Oil Cooling /100%

Image System

X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 12bit Deep
Monitor: High Resolution Color, LCD Accord, 17 inch
(19 inch optional)
Image Processing: Edge enhancement, image strengthening, image
lightening,, reducing darkening, image returning,image retrieval.
Image Grey Level: 4096
Image Processing: 24bit for processing real time
Image storage: Storage 60000 pictures in real time
Zoom: max 16 Times Enlarge, Whole screen continuous observation

Advantage:

Assist of detecting organic and inorganic items such as
weapons, explosives and narcotics using different colour show
