Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Small size Baggage and Parcel Inspection 5030 for Office security check scanner
Specifications
Brand Name :
SECUSCAN
Model Number :
AT5030C
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
300 sets/month
Delivery Time :
within 7 working days
Packaging Details :
Wooden Pallet
Port :
Shenzhen
Brand :
OEM accepted
Business Type :
Manufacturer
Conveyor Speed; :
0.22m/s
Tunnel size :
500mm*300mm
Conveyor Max load :
150KG
Service :
Free training in factory, technic support online
Resolution :
<0.101mm Metal Wire
Penetration :
28-34mm Steel
Have in stock :
Yes
Anode Voltage :
140Kv
Baggage Counter :
Yes
Automic Scanning :
Yes
Bidirectional scanning :
Yes
Description

Small size Baggage and Parcel Inspection 5030 for Office security check scanner

General Specification

Tunnel Size:

500(W)*300H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

150kgs

Wire Resolution:

32AWG to 38 AWG

Spatial resolution:

horizontal:1.3 or 1.0mm,
vertical: 1.3 or 1.0mm

Penetration:

28 to 34 mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<1μGy/h (at a distance of 5cm From external housing)
Pass rate: 720 bags per hour

Beam direction:

Diagonal

Generate angle:

80 degree

Anode Voltage:

140Kv

Anode power:

0.4 to 1.2mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic), 12bit Deep

Monitor:

High Resolution LCD Accord, 17 inch

Image Processing:

Edge enhancement, image strengthening, image lightening,

reducing darkening, image returning, image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 768 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage100000 pictures in real time

Zoom:

64 Times Enlarge, Whole screen continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1 KW (max)

Noise:

<60db

  • The SECUSCAN X Ray Baggage Scanner offers another way to see inside of handbags,briefcases. It popular accepted as a nonintrusively optimize security measure .
  • AT5030A give you innovative and costeffective solutions. It¡s a great help to exclude the threats and contraband.
  • AT5030A is friendly operation system, and easy to maintenance .
  • SECUSCAN is together with you to antiterrorism


Applications:

01. railway station
02. Transport terminals,
03. Buildings,
04. Factories (to find needle in clothing, shoes, bags),
05. Courthouses,
06. Embassies,
07. Military installations,
08. Prisons,
09. Hotels,
10. Schools ,
11. Convention centers,
12. Security checkpoints
13. Special events location

Detailed Product Description:

1 SECU SCAN X RAY SYSTEM offers a modern technology to secure entry checkpoints for important locations like airports, transport terminals, buildings, and so on.

2 Our systems screen baggage and parcel, to detect contraband, weapons, dangerous and illegal items. Model AT100100 easily accommodates the inspection of big size baggage and parcels.

3 SECU SCAN X RAY SYSTEM is based on user-friendly design with ergonomic operator control panel and adjustable control panel stand. It is easy to installation and maintenance. Over 100 systems per month installed in china and abroad.

4 SECU SCAN branded products received certifications of CE, Test report from China Ministry of Public Security and Copyright for image Operation software SPHOTO.

Our Factory

Small size Baggage and Parcel Inspection 5030 for Office security check scannerSmall size Baggage and Parcel Inspection 5030 for Office security check scanner

Small size Baggage and Parcel Inspection 5030 for Office security check scannerSmall size Baggage and Parcel Inspection 5030 for Office security check scanner

Shipping and Packing

Small size Baggage and Parcel Inspection 5030 for Office security check scannerSmall size Baggage and Parcel Inspection 5030 for Office security check scannerSmall size Baggage and Parcel Inspection 5030 for Office security check scannerSmall size Baggage and Parcel Inspection 5030 for Office security check scanner

Company Profile

SEE(Security Electronic Equipment Co., Limited), is a high-tech company integrating R&D, manufacturing, engineering,training and services. We run SECU SCAN as the top brand. As a reliable supplier, we continue produce good quality products, give professional technical support.

SEE gradually establishes a very comprehensive product range covering X-ray machines with different tunnel size, Walk through Metal Detector, Hand-held Metal Detector, Dangerous Liquid Scanner, Explosive/Narcotics Trace Detector, Under Vehicle System and etc.

SEE security systems have been used in different countries and regions in airports, seaports,customs, railway stations, long-distance bus stations, jail houses, courts yard, and many other security-related applications.

With ISO9001 management system, SEE always keeps running with high efficiency by balancing development on her product R&D, manufacturing, quality control and service according to ISO strict international standard requirements.

With global marketing strategy, SEE provides innovative and dependable security solutions to our global customers and makes every effort to continually exceed our customers' expectations.
Life is precious SEE puts its efforts on public security solution.


Our Service
All products purchased in our company are guaranteed to keep in good repair for one year.
If quality problems happen in guarantee period, our company will maintain for free.
Additionally, our company provides technical support and fittings for life.
After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time.
If you are caught in some problems when using our products, welcome to contact us at any time.
