Specifications
Brand Name :
SECUSTAR
Model Number :
JC1833
Certification :
CE ISO FCC
Place of Origin :
CHINA
MOQ :
1UNIT
Price :
1-900USD/pcs
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200pcs/Month
Delivery Time :
5-7 days
Packaging Details :
Carton packing
Model :
JC1833
Material :
Aluminum
LCD :
7 Inch
Zones :
33 detection zone
Alarm :
Sound and Led alarm
Weight :
70kg
Power :
110-240Voltage working
Waterproof :
IP68 Level
Description

SECUSTAR JC1833 Model LCD WALK THROUGH METAL DETECTOR 33 ZONES :

Technical Features:

  • Operating voltage: 70VAC – 270VAC / 50Hz – 60Hz
  • Power: 10W Stand By – 20W (Alarm)
  • Ambient Temperature: -20°C to +70°C
  • Package Dimensions (W x L x H):
  • Box 1: 81 x 235 x 21 cm (65 Kg)
  • Box 2: 43 х 81 х 27 cm (14 Kg)
  • Gross Weight: 79 Kg
  • Net Weight: 70 Kg
  • Net ­Passage: 74 x 68 x 200 cm
  • External: 85 x 68 x 220 mm
  • Whilst Normal Operation, displays IN/OUT Counters and Security Level on LCD without abbreviations
  • Auto Calibration
  • Capable to Detect both Ferrous and Non-Ferrous Metallic Threat Objects.
  • Detects all threat objects even if concealed.
  • No Interference between Zones and No False Alarms
  • Multi-Zone – 33 Real Matrix Detection Zones(Up/Middle/Down and Left/Middle/Right)
  • Audio and Visual Alarm:
  • Displays Location of the Detected Metal Objects with Continuous LED Zone Indicators on Both Side Panels from top to bottom
  • Detects Metals regardless their orientation
  • 300 sensitivity levels, 300 adjustable sensitivity steps at each, Preset NILECJ Sensitivity Program, – 7 Preset Security Programs
  • Automatic Frequency Selection Feature
  • Metal Density Display at 10-level-VU meter with green, yellow, red LEDs
  • Superior Discrimination, Pin Point target location identification with Graphical zone display on Control Unit
  • VLF technology, No effects on Pace Makers, Pregnant and Magnetic Media
  • Green/Red bi-colour track through LED’s, easily allows sight from distance
  • 80 Persons/Minute and LED Alarm Indicators side panels

Trade Terms:

Unit Price Negotiation
Price Term EXW, FOB ,CIF
Payment term T/T Westerunion sight L/C
Delivery time 5-7days after confirming orders
Packing ways Carton packing or wooden case
Production ability 500-600pcs per month
Quality warranty 12months ,extension to 18/24 months
