Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Specifications
Model NO. :
Q41F-16P
Driving Mode :
Electric,Pneumatic,Manual
Nominal Pressure :
PN1.0-32.0MPa
Channel :
Straight Through Type
Structure :
Floating Ball Valve
Type :
Floating Ball Valve
Function :
Industrial Usage, Water Industrial Usage, Househol
Temperature :
High Temperature
Standard :
GB/T12237
Application :
Industrial Usage, Water Industrial Usage, Household Usage
Net Torque :
7n.M-1250n.M
Transport Package :
Plywood Case
Specification :
1/2"-12" / DN15-DN300
Trademark :
Xuteng
Origin :
Zhejiang China
HS Code :
8481801090
Supply Ability :
10000PCS/Week
Package Size :
30.00cm * 20.00cm * 23.00cm
Package Gross Weight :
5.000kg
Media :
Oil,Water,Gas,Acid
Material :
Stainless Steel
Connection Form :
Flange
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Place of Origin :
Zhejiang China
Certification :
CE/SGS/ISO9001
MOQ :
1
Payment Terms :
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Price :
negotiate
Description
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
The ball and valve seat of the metal hard-sealed ball valve are completely metal-to-metal sealing. In order to ensure the reliable sealing of the valve under various temperatures and pressures, a variety of advanced ball and The hardening technology of the valve seat includes supersonic spraying, nickel-based spray welding, special surface hardening, cemented carbide spray welding and the use of high-strength and high-hardness ceramic materials.
The surface hardness of the ball and valve seat can generally reach HRC60 or more, and the highest HRC74 and above. The temperature resistance of the sealing surface material can reach 540 ºC, and the maximum can reach 980 ºC.
The bonding strength of the material can reach more than 10000PSI, and the sealing surface material also has good abrasion resistance and impact resistance. Metal hard-sealed ball valves are suitable for most harsh working conditions.


Product Name Pneumatic Floating Ball Valve(Q41F)
1. Material Stainless Steel WCB/304/316( CF8/CF8M)
2. Size 1/2"-12" ( DN15-DN300)
3.Certificate ISO9001 & CE
4. Port Ningbo/Shanghai
5. Working Pressure PN1.0-32Mpa
6. Working Temp. -20ºC~200ºC
7. Seal A105+Carbide,F304+Carbide,F316+Carbide
8. Locking handle Option
9. Inspection& Testing According to API598
10.Delivery Time 15~20 Days
11.Payment Terms T/T, Western Union, PayPal, etc.
30% prepayment, 70% balance paid before shipping or against copy of BL
12.Warranty 12 Months after leaving factory
13.Others We also manufacture High Platform Flange Ball Valve, Gate Valve, Globe Valve, Check Valve & Y Strainer
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material



Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Company style

Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material

Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Company Honor
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material
Floating Ball Valve Q41F with Pneumatic Actuation and Stainless Steel Body Material

FAQ

Q : Are you a factory or a trading company?
A : We are a R & D factory.

Q : Which country do you export to?
A : We can export to any country according to buyer's need.

Q : Do you accept the customized order?
A : YES!

Q : What is your main market?
A : Southeast Asia, Middle East, North America, South America, Europe, etc.

Q : Can you give me a discount?
A: As you know, we are the manufacturer, so please trust us that our prices are competitive.
If the quantity is large, we can consider giving you a discount.

Q : If the product has quality problems, what will you do?
A : We will be responsible for all quality problems.


Q :What is your payment term?
A :1.T/T, 30% down payment, balance paid before shipment.
2. Letter of credit.

Q: If the product has quality problems, what will you do?
A: We will be responsible for all quality problems.
