12 Core MPO to SC/UPC single Mode Fiber Optic Patchcord For MPO Cassets
12 Core MPO to SC/UPC single Mode Fiber Optic Patchcord For MPO Cassets
Specifications
Brand Name :
XYFiber/OEM
Certification :
SGS,RoHS
Place of Origin :
Shanghai,China
MOQ :
1PCS
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
1000PCS/Day
Delivery Time :
3-5 days
MPO :
Male/Female
Cable Jacket :
LSZH
Cable Type :
0.9MM
Description

MPO to SC Fiber Optical Patch Cord 12 Fiber For MPO Cassettes

Features:

  1. MPO patch cords are available in 3 different wire map configurations: Straight, Total Flipped or Pair Flipped

  2. MPO connector complies with IEC-61754-7 & EIA/TIA-604-5.

  3. MPO patch cables are available in multi-mode and single-mode fiber cable.
  4. Small Form Factor, 12Fibers or 24Fibers push/pull optical connectors

  5. Jacketed cable is compliant with NFPA 262 Optical Fiber Nonconductive Plenum (OFNP) or IEC-60332 Low Smoke Zero Halogen (LSZH) flame rating, compliant with Directive 2002/95/EC (RoHS) and REACH SvHC.

  6. 100% tested (test data supplied) - Assures verified optical performance for improved network integrity.

Applications:

Performance of Assemblies MTP / MPO Termination

Specification:

Type/Performance Singlemode(APC polish) Multimode(PC / Flat Polish)
Standard Elite Low Loss Standard Elite Low Loss
Maximum Insertion Loss ≤ 0.75dB ≤ 0.35dB ≤ 0.60dB ≤ 0.35dB
Return Loss ≥ 50dB N/A
Operating Temperature -40°C to 80°C 40°C to 80°C
Test Wavelength 1310nm 850nm

Packing:

PE bag with stick label (we could add customer's logo in the label.)
